| 4UDS-110 |
| PROJECT | DESIGN VALUE | PROJECT | DESIGN VALUE |
| Structural Style | Three Point Suspension | Type of excavation device | Movable Shovel |
| Working Size (length*width*height) | 2900*3200*1700mm
| Blade Material | 65Mn |
| Transport Dimensions (length*width*height) | 2900*2400*2300mm
| Digging Depth Adjustment Range | 0~250mm |
| Overall Weight | 800kg
| Depth Limiting Mechanism Type | Depth Limiting Mechanism Type |
| Working Width | 1100
| Conveyer Type | Conveyer Type |
| Operation Efficiency | ≥0.17 ha/h
| Conveyor Chain Clearance | 45mm |
| Supporting Power/Machine Horsepower | ≥70HP
| Chain Bar Material | 55CrSi |
| Matched To The Power Output Shaft Speed | 540r/min
| Collection method | Instant loading |
| Matching Hanging Width | 600mm
| Collection height | ≤1500mm
|
