| Scan mode | Standard mode R | Hyperfine mode B |
| Laser source | 7 red laser crosses (+ 1 extra line) | 5 blue parallel laser lines |
| Accuracy | Up to 0.02mm | |
| Built-in photogrammetry | Support | |
| Volumetric accuracy (based on part size) | 0.02 mm+0.035 mm/m | 0.01 mm+0.035 mm/m |
| Volumetric accuracy with high-precision reference bar | 0.025 mm/m (Optional) | |
| Measurement resolution | 0.050 mm | 0.010 mm |
| Measurement rate | 650,000 measurements/s | 650,000 measurements/s |
| Laser class | 2M(eye-safe) | |
| Scanning area | Up to 550 mm × 600 mm | |
| Stand-off distance | 200 mm ~ 420 mm | |
| Depth of field | Up to 550 mm | |
| Portable CMM | Optional | |
| Single point repeatability | 0.03 mm | |
| Intelligent edge inspection | Optional | |
| Edge accuracy | 0.030 mm | |
| Software | ScanViewer | |
| Piple inspection in software | Optional （support YBC/LRA data） | |
| Output formats | .stl, .ply, .obj, .igs, .stp, .wrl, .xyz, .dae, .fbx, .ma, .asc | |
| Interface mode | USB 3.0 | |
| Operating temperature | -10~40 °C | |
| Patents | CN204902790U, CN206905709U, CN107202554, CN204902785U, CN106403845, WO2018049843, CN106500627, WO2018072434, CN106500628 , WO2018072433, CN206132003U, CN104501740，US10309770B2 | |
