Cogged Banded V Belt for Industrial and Agricultural Power Transmission

Product Description

The SMSOUTH V-banded belts and cogged V-banded belts are an excellent choice for virtually any application where increased horsepower capacity or output is needed. Or where conventional, single or multiple belt drives are impractical because of space or weight limitations.
SMSOUTH 's banding process assures smoother, more quiet operation. the specially compounded wrap construction is ideal for clutching operations. And it won't turn over or jump off the drive. It's oil and heat resistant and antistatic, too. Typical applications for banded V-Belts include vertical shaft drives, V-Flat drives and clutching drives. Banded V-Belts are recommended for use where belts vibrations or blet whip causes unsatisfactory results when conventional multiple V-belts are used. They are available in Classical cross sections as (A, B, C, & D), narrow cross sections as, (3V, SV, & 8V). And Metric cross sections as (SPA, SPB, SPC), The Raw edge cogged banded cross sections are: (RAX, RBX, RCX, R3VX, R5VX, R8VX)

Tope Surface Upper belt structure Polyester tension cord. low maintenance Embedding compound Chloroprene compound with transverse oriented fiber Moulded cogs

Characteristics: 1. Maintenance-free 2. Reliable running performance 3. Outstanding transverse stiffness 4. High power transmission capability 5. Frame material: polyester string, cord 6. Enveloped in special rubber-impregnated fabric 7. Elastomeric material: chloroprene rubber 8. Compact, high working speed transmission and transmission of general motive force 9. Used in transmission devices in harsh conditions such as large power and high impact applications

Profiles
Section	Top width(mm)	Height(mm)	Pitch Distance(mm)	Length Range (inch)
RA(AJ)	13	10	15.9	47"-197"
RB(BJ)	17	13	19	47"-394"
RC(CJ)	22	16	25.5	79"-590"
RD(DJ)	32	21.5	37	157"-590"
RE(EJ)	38	27	44.5	196"-708"
R3V(9NJ)	9.7	9.7	10.3	47"-197"
R5V(15NJ)	15.7	16	17.5	59"-394"
R8V(25NJ)	25.4	25	28.6	79"-394"
RSPA	13.6	12	/	47"-197"
RSPB	17	16.5	/	59"-394"
RSPC	22	21	/	118"-492"
RAX	13	10	15.9	24"-150"
RBX	17	13	19	50"-195"
RCX	22	16	25.5	100"-195"
R3VX	9.7	10	10.3	24"-150"
R5VX	15.8	16	17.5	50"-200"

Application

Most of banded V belts are primarily used for special problem solutions in mechanical engineering and commercial vehicle construction. The advantages of the SMSOUTH KB banded v belt with aramid tension cords become obvious when dealing with heavy loaded drives in mechanical engineering and in the agricultural machine industry. These SMSOUTH KB provide the highest possible level of reliability wherever high temperature impacts and low adjustment ranges are present.

FAQ:
1. How many years have you been in hose/belt business?
30 years
2. Do you have big and famous customer? How many years do you cooperate with them?
Yes, we are cooperating with a big multinational company in USA more than 15 years. We are the sole purchasing agency of the company in China.
3. What about your quality level?
Because we export big amount to the multinational company, our quality of all productions are in high level. Our products have been satisfied with our customer more than 15 years.
4. Which countries are your main sales?
America, South America, Africa,Midde East Countries,Australia, New Zealand,Europe
5. What's your acceptable payment terms?
T/T and L/C are acceptable, other payments can be negotiated.

6. How long is the delivery time?
Usually we can effect shipment within 20 days after confirming the order, but for coupling, it will be a little long ,about 45 days.

7.The how about the packing?
The packing are plastic paper, woven bag, pallet and carton as per the items ordered.
8. What's the Minimum order quantity?
The minimum order amount is USD3500.
9. Can we place belt,hose, fitting , coupling, rubber sheet all are in small order, and ship together?
Sure, we can do. Each week, we have lots of goods are waitting to ship. We can consolidtae all goods in one container. It's our advantage

10.What are the quality standards passed?
FDA,ISO,SGS,ROHS,REACH

---
