| US$637.20 | 1 Piece (MOQ) |
| Model No. | YKR-007TD1 | YKR-010TD1 | YKR-013TD1 | YKR-017TD1 | YKR-021TD1 | YKR-030TD1 | YKR-030TD3 | YKR-035TD3 |
| * Heating Capacity at Air 26ºC, Humidity 80%, Water 26ºC in, 28ºC out | ||||||||
| Heating Capacity (kW) | 7.6~1.7 | 9.5~2.3 | 13~3.0 | 17~3.8 | 21~4.8 | 28~6.8 | 28~6.8 | 35~8.8 |
| Power Input (kW) | 1.12~0.11 | 1.40~0.15 | 1.91~0.19 | 2.5~0.24 | 3.09~0.30 | 4.12~0.43 | 3.97~0.43 | 5.15~0.56 |
| COP | 15.8~6.8 | 15.8~6.8 | 16~6.8 | 15.8~6.8 | 15.8~6.8 | 15.8~6.8 | 15.8~6.8 | 15.8~6.8 |
| * Heating Capacity at Air 15ºC, Humidity 70%, Water 26ºC in, 28ºC out | ||||||||
| Heating Capacity (kW) | 6.1~1.4 | 7.6~1.9 | 9.8~2.3 | 13.5~3 | 16.5~3.8 | 23~5.5 | 23~5.5 | 25.5~6.4 |
| Power Input (kW) | 1.24~0.18 | 1.55~0.25 | 1.96~0.30 | 2.76~0.39 | 3.37~0.5 | 4.7~0.72 | 4.7~0.72 | 5.2~0.84 |
| COP | 7.6~4.9 | 7.6~4.9 | 7.6~5 | 7.6~4.9 | 7.6~4.9 | 7.6~4.9 | 7.6~4.9 | 7.6~4.9 |
| * Cooling Capacity at Air 35ºC, Water 29ºC in, 27ºC out | ||||||||
| Cooling Capacity (kW) | 4.2~1.0 | 5.3~1.3 | 7.2~1.7 | 9.4~2.1 | 11.6~2.7 | 14.9~3.8 | 14.9~3.8 | 19.3~4.9 |
| Power Input (kW) | 1.11~0.15 | 1.4~0.19 | 1.89~0.25 | 2.47~0.31 | 3.05~0.4 | 3.92~0.57 | 3.92~0.57 | 5.08~0.73 |
| EER | 6.6~3.8 | 6.7~3.8 | 6.7~3.8 | 6.7~3.8 | 6.7~3.8 | 6.7~3.8 | 6.7~3.8 | 6.7~3.8 |
| * General data | ||||||||
| Power supply | 220~240V/1/50 | 380~415V/3/50 | ||||||
| Max Power Input (kW) | 1.55 | 1.78 | 2.2 | 2.6 | 3.2 | 4.45 | 6.43 | 6.93 |
| Max Current (A) | 7.3 | 8.3 | 10.2 | 12 | 14.7 | 20.4 | 7.9 | 11.3 |
| Water Flow Volume (m3/h) | 2.5 | 3.5 | 4.5 | 5.5 | 6.5 | 9 | 9 | 12 |
| Refrigerant | R32 | |||||||
| Heat Exchanger | Titanium | |||||||
| Air Flow Direction | Horizontal | |||||||
| Kind of defrost | by 4 way valve | |||||||
| Working temp. range (ºC) | -15~43 | |||||||
| Casing Material | ABS | |||||||
| Water Proof Level | IPX4 | |||||||
