Custom CNC Machining Plastic Product UHMWPE Guide Rail Mechanical Parts

Product Description

Product Description
Ultra high molecular weight polyethylene(UHMW-PE) performance characteristics:
Ultra high molecular weight polyethylene (UHMW-PE) is a thermoplastic engineering plastic. It has the superior performance of most plastics, impact resistance, low temperature resistance, wear resistance, chemical corrosion resistance, self lubrication, absorption of impact energy. In recent years, UHMW-PE plastic products have been widely used in various fields in the world, and the demand is increasing.
Ultra high molecular weight polyethylene (UHMPE) is synthesized by ziegler type high efficiency catalyst at low pressure, and its molecular weight is more than 9-10 million according to needs. Considering the thermal degradation of molecules during processing, high density polyethylene with viscoaverage molecular weight greater than 9 million can be processed into various products to have better performance.
Advantages:high impact strengthlow friction coefficienthigh abrasion resistanceUV + Ozone resistantNonconducting (optional)100% recyclable, non-rotteningCut to size sheet all size is available with us

Xinxing is a professional custom plastic fabrication service and solution provider in China. Apart from High Density Polyethylene sheet and dual color sheet, we also offer a broad range of custom HDPE/UHMWPE machined parts such as PE cutting board, wear blocks, wear strips, rods and tubes, etc. The HDPE/UHMWPE parts are well suited to the food industry where low friction, wear and buffer strips on food production lines are important. HDPE Sheet is also important within the conveyor industry, water industry and fishing industry because of its very low moisture absorption and good chemieal resistance. HDPE/UHMWPE Sheet can be machined quite nicely on CNC or cutting machine to make different machined parts and provide a nice smooth surface.
Size
Support customized parts, customized according to drawings, optional colors, 100% raw materials


Advantages
1, high wear resistance: in all current engineering plastics UHMW-PE wear resistance is the best, the most eye-catching. The higher the molecular weight, the more wear-resistant the material, and even more than many metal materials (such as carbon steel, stainless steel, bronze, etc.).
2, corrosion resistance: in alkali solution is not corroded, can be used in 80ºC concentrated hydrochloric acid, in 75% concentrated sulfuric acid, 20% nitric acid stable performance, it is also very stable to seawater, liquid detergent.
3, very low friction coefficient: static friction coefficient of 0.07, good self-lubrication, is an ideal bearing, sleeve, slider, lining material. Choosing UHMW-PE as the friction part of the equipment can not only improve the wear life, but also get the effect of energy saving.
4, impact resistance: impact resistance in plastic first, whether external force strong impact, or internal pressure fluctuation, it is difficult to crack. Its impact strength is 10 times of nylon 66, 20 times of PVC, 8 times of PTFE; Especially in the low-temperature environment, its impact strength reaches the highest value, and its flexibility can provide a very safe and reliable guarantee for the conveying system.
5, aging resistance: stable performance, good aging resistance, ground, underground can be buried, 50 years of aging. According to ASTM method determination (load 4.6kg/cm2), the thermal deformation temperature of 85ºC, the use of temperature up to 90ºC, under special circumstances, allow the use of higher temperature. Uhmw-pe is a kind of excellent toughness material, its low temperature resistance is also very excellent, at -269ºC, still has a certain ductility, and there is no sign of brittleness. But the linear expansion coefficient is large, the thermal conductivity is very poor, so in the design of products, to give full attention.
6, electrical performance: large volume resistance, breakdown voltage up to 50KV/mm, dielectric constant is 2.3. In a wide range of temperature and frequency, suitable for electrical engineering structural materials.
7, health non-toxic: UHMW-PE tasteless, non-toxic, odorless, itself non-corrosive, with physiological inertia and physiological adaptability. The US Food and Drug Administration (FDA) and the US Department of Agriculture (USDA) allow it for use in situations where it comes in contact with food and drugs.

Specification

Material	UHMWPE, HDPE
Thickness	1-300mm
Size	customized
Processing Service	Cutting, Moulding, Injection Mould
Product name	HDPE UHMWPE plastic part
Color	white black
Application	Various parts
Raw material	100% Virgin Material
Shape	Customized Shape
Density	0.94-0.98g/cm3
Logo	Customized Logo Acceptable
Water absorption	Under 0.01%
Sample	Avaliable
Quality	High-quality

Company Profile
Shandong Ningjin Xinxing Chemical Co.,Ltd Established in 1989, Xinxing has a history of 35 years in Manufacturing ENGINEERING plastics.
Now it is the largest and most professional manufacturer of Engineering plastics, such as UHMWPE/HDPE Sheets, Boards, Rods, Outrigger Pads, Marine Fender Boards, Ground Protection Mats, Rink Ice Panel and other Machined Processing Parts.
We have advanced Extruding and Compression machines, CNC devices, can make any shape product according to customer's requirements.
Xinxing has 3 factories which passed ISO9001 and ensure all of products compliance with its standard. Our products are used widely in electric power, ports, mining, coal, paper, textile, chemical industries. They are popular in Canada, USA, Russia, Japan, England, Indonesia, Malaysia, India, Italy, South Africa, Chile, Belgium, etc.
Looking forward to your visit!
Packaging & Shipping

Certifications
FAQ
1.Are you a manufacturer or a trading company?We're one of the leading PE manufacturer in China for more than 20 years.2.Is sample available?Yes.The smaller sample is FREE, but you should pay the freight charge.3.Is the size fixed?No.we can meet your needs according to your requirement. That is to say, we accept to customize.4.Is it all right to make customer's own brand name?That's all right to engrave your own brand name.5.Can you special order a product for me?We are typically able to special order products for customers.6.what can you buy from us?Crane Outrigger Pads, Ground Protection Mats, HDPE Sheet, UHMWPE Fender Pads, UHMWPE Sheet7.why should you buy from us not from other suppliers?nearly 20 years experience in prducing HDPE sheet There is a professional techique and work team good quality,timely delivery,good service and competitive are our advantage8.what services can we provide?Accepted Delivery Terms: FOB,CFR,CIF,EXW;Accepted Payment Currency:USD,CNY;Accepted Payment Type: T/T,L/C;Language Spoken:English,Chinese

---
