Three Axies 250CNC Multifunctional Machinery for Grinding and Crushing Tasks

Product Description

250/2550CNC Surface Grinding MachineThree Axies 250CNC Multifunction Grinding Machine Tool
At Cheng Yu Machinery Technology Co., Ltd., we embrace the philosophy of unwavering advancement in every creation, reserving the liberty to enhance specifications, mechanics, or designs at any given moment, without prior notice or accountability.

	parameter	unit	CNC-250	CNC-2550
general picture	Table size (x*y)	mm	200×500	250*500
	X axis travel	mm	580	580
	Y axis travel	mm	230	280
	Max center of wheel to table	mm	380	380
	Maximum load	kg	200	200
Table	Table T cell specification	mm×N	14×1	14×1
	Table speed	m/min	0-25	0-25
Y axis	Minimum feed	mm	0.001	0.001
	Single feed		0.1~10	0.1~10
	Fast moving speed	mm/min	0~1200	0~1200
Z axis	Minimum feed	mm	0.001/0.01	0.001/0.01
	Fast moving speed	mm/min	0~800	0~800
grinding	grinding wheel size max	mm	Φ200×Φ31.75×19
	grinding wheel speed	R.P.M	0~3600	0~3600
motor	spindle motor	HXP	2×2	2×2
	the Z axis motor	W	750	750
	the Y axis motor	W	750	750
	the X axis motor	W	1500	1500
	cooling motor	W	90	90
Size	height of machine	mm	2000	2000
	floor space	mm	2000×1350	2000×1450
	weight(about)	kg	1450	1550

Nestled in the innovative hub of Dongguan City, Guangdong Province, Cheng Yu Machinery Technology Co., Ltd. stands as a beacon of excellence. With roots tracing back to Taiwan's 30-year legacy in crafting superior grinding machinery, our team is fueled by both tradition and cutting-edge insight, showcasing a blend of seasoned expertise and progressive technology. In the ever-evolving landscape of CNC machine tools, the future embraces high-speed precision, intelligent integration, versatile composability, and environmentally conscious design. The direction is clear: towards open, networked systems, fostering groundbreaking efficiency and sustainability. Proudly positioned in the heart of Dongguan, Cheng Yu Machinery Technology Co., Ltd. specializes in top-tier machine tool production and processing. Our commitment to 'technology, innovation, and reliability' underpins a meticulous quality policy, aiming to deliver excellence. We delve deeply into our customers' process needs, production demands, and quality aspirations, making strides in design and manufacturing. Advancing the CNC industry with high-automation, precision, and quality, our operations are anchored by a robust quality management system, state-of-the-art equipment, and unparalleled craftsmanship. In tune with market demands, Cheng Yu Machinery innovatively designs and manufactures a suite of high-precision CNC machinery. From surface grinding machines to forming machines, punch grinders to gantry rail grinders, our portfolio extends to industrial robots and automated production lines. Here's a glimpse into our esteemed CNC grinding machine series: I. HS series 618 / 250 / 3060 / 4080 / 40100 (available in both servo and hydraulic variants) Processing capacity: Versatile, adept at surface grinding and precise grooving Equipped with our groundbreaking patented hydraulic control system (hydraulic variant) Functionality: Features include grinding programs for flat surfaces and groove cutting. Flexible feed modes: Choose from front, back, left, or right, with each grinding program retaining memory of the feed mode. Automatic protection with grinding wheel overload shutdown. II. (servo type / hydraulic type) Processing capacity: Comprehensive, encompassing surface grinding, grooving, and innovative combined scheduling Patented hydraulic control system (hydraulic type), ensuring unparalleled precision and reliability Functionality: A repertoire of grinding programs including surface, groove, sole, side, and intricate displacement grinding at varying distances and depths. Advanced grinding wheel dressing: Automated plane dressing based on set parameters for rough and fine grinding, with automatic compensation during cycles. Sophisticated feed mode options: Selectable from front, back, left, or right, with memory retention for each grinding program. Facilitates both equidistant and non-equidistant grooving with unequal precision. 3. The dynamic four-axis CNC grinding machines, available in both horizontal and vertical configurations Processing types: Masterful in executing arbitrary equal division and innovative skipping tooth processing Waist circle precision: Enter AB dimensions for seamless accuracy Tailored triangle fillets: Input inscribed circle size B and fillet size R for perfect results Quadrilateral fillets: Specify side lengths A, B, and fillet size R for flawless execution Eccentric circles: Input eccentricity and diameter parameters for tailored craftsmanship Circle: Effortlessly enter both the starting and ending diameters to achieve precision in your projects. Arc: Simply input the arc size and specify the desired rotation angle to ensure meticulous crafting. Step Difference and Rotation Profile: Seamlessly manage intricate details and profiles with ease. Processing Schedule: Save your processing schedule as a file for hassle-free and quick future access, ensuring efficiency in every task.

---
