| 1 | cutting capacity | round | Φ15 mm--Φ70 mm |
| square | 15 mm--60 mm | ||
| Cutting length | 5mm--500mm | ||
| Front cut length | 10mm-40mm | ||
| Leaving length | 70mm--70+cutting length | ||
| 2 | saw blade | Teeth number | 60, 72, 80, 120 |
| size | Φ285xΦ32x2.0 mm | ||
| 3 | saw blade axis | rev | 60/80/100/120rpm |
| Cutting drive | Servo motor+ball screw | ||
| 4 | Material feeding | Feeding speed | 8-12m/m |
| Cutting speed | 4-12mm/s | ||
| Feeding mode | Clamp feeding | ||
| Feeding drive | Servo motor+ball screw | ||
| 5 | Saw blade motor | AC 7.5KW 4P | |
| 6 | Oil pressure motor | AC 3.75KW 4P | |
| 7 | Oil tank capacity | 100 L | |
| 8 | Machine size | 2100x1500x1620mm | |
| 9 | Machine weight | 1500kg |
| FAQ: |
| 1) Q: Can i have your quotation? A: First, please offer us the information of your material size, without these parameter, we are not able to recommend you the suitable machine 2) Q: Do you have overseas service? A: No,but we normally help our customers to solve the problems through phone,Email, skype, internet video. high efficiency. We offer one year guaranteen, within one year, if component of the machine broken, we freely offer the component, but the delivery fee should be paide by client 3)Q: What is the voltage and Hertz in your country? A: In China,the Voltage is 380V(3 Phase), the Hertz is 50HZ, we can change the voltage and Hertz according to your requirment. 4) Q: How about the payment term A: T/T 30% deposit, 70% of balance paid at the sight of bl copy send by email. |
