Full-Automatic Roll-Roll Continuous Free Adhesive Tape Die Cutter

Product Description

MQ-320 Full-automatic Roll-Roll Continuous Free Adhesive Tape Die Cutter
Description :
This machine die cuts through flat pressing and high precision unit while shifting materials and slitting are controlled through servomotor. The printing abel's two-faced and Lengthways the color marks from three optics electric eyec to have exquisite tracking to locate, die cut, collect the discarded waste, slit or auto label in one processing. It is very applicable to die cut free paper adhesive tape, Dacron film trademark and laser anti-false trademark. It is an ideal equipment for soft printing machine, continuous thread printing machine, intaglio printing machine and anti-false trademark die press machine and is also the most efficient equipment for whole wheel rotation quick roll trademark printing machine. It is also applicable to die cutting to form for the Electronic and adhesive tape sectors.
Note: The function can be expanded --
1. Die membrane trademark stickers.
2. Delay Reel Stamping Die
3. Stamping Die laser hologram
Main Technical Parameter:

Model	MQ- 320
Speed	20-180Meeting /Pm
Roll diameter	500mm
Web maximum width	320mm
Die maximum width	300mm
Die maximum length	290mm
Positioning accuracy	± 0.1mm
Total power	2.2kw
Supply Voltage	220v10%
Weight	1500kg
Dimension	2.8(L)* 0.95(w)* 1.4(h) (m)

FAQ
1.Is your company trading company or manufacturer?
We are manufacturer specialized in plastic machine for more than 35 years, all of our engineer with more than 20 years experience.
2. Where is your factory? How can i visit your company?
Our factory is located in Ruian city,zhejiang province, China.
Its about 40 minutes from shanghai by plane(4 hours by train). We will pick you up on airport or station. Welcome to visit our manufacture.
3 What's the scale of your company?
Our company covers 14000 square meter, over 11000 square meter of which is bulding area, consisting over 100 staffs, 20 engineers for technical support.
4 How long is your delivery time?
Our delivery time is 30-45 days. Ugently, we can make your machine first. About 10 days.
5 What's your warranty policy?
18 month guarantee and 1 year after-sales maintenance.

6 What package do you use for the product?
Covered with plastic film. Wooden box package need extra cost .

7 Does your manufacture provide installation service?
Our engineer can go to customer factory to installation. Buyer should prepare materials to test the machine in advance and should be responsible for the cost of supplier's technician, including round air tickets, visa cost, accommodation and salary since the day start out until the day arriving at factory.
8 What are your terms of payment?
We accept T/T, L/C. western union.
9 How could we do if the parts broken within warranty?
We would express the free replacement parts during the warranty date.
10 Does your engineer understand English?
Our engineer understand a little English. But don't worry, We have professional translators.And All our engineer have more than 20 years machine installation experience.

---
