EV— Motor_55/120kw— Transmission-Amounted Electric Drive

Product Description

Product Description Driven by a permanent magnet synchronous motor, the AMT automatic transmission is coaxially connected with the motor, and the transmission speed and torque increase characteristics are used to achieve the effect of matching a smaller motor to directly drive a large motor.
Detailed Photos
Product Parameters

Model	Vehicle model	Vehicle weight	Gearbox	Motor	Max output torque
TED1360	4.5T Truck	4.5-7T	2 Ratio AMT	300/500Nm,60/120kW	1365Nm
TED2330S	7.5T Truck	7-12T	2 Ratio AMT	350/850Nm,75/120kw	2330Nm
TED3010S	8-10m Coach/10m Bus/12T Truck	11-14T	2 Ratio AMT	500/1100Nm,80/160kW	3015Nm
TED3380S	10m Coach/12m Bus	14-25T	2 Ratio AMT	500/1300Nm,120/185kW	3380Nm
STED7000S	14-18T Truck/Special vehicle	14-18T	4 Ratio AMT	500/1100Nm,100/185kW	7000Nm
HTED16000	25T Heavy Truck	25-30T	4 Ratio AMT	850Nm/1950Nm,180/300kw	16360Nm
HTED20000L2	49T Heavy Truck	31-49T	4 Ratio AMT	1200Nm/2400Nm,250/380kw	20136Nm
HTED20000L	55T Heavy Truck	35-60T	4 Ratio AMT	1500Nm/2400Nm,270/405kw	20136Nm
HTED20000H	60-90T Heavy Truck	60-90T	4 Ratio AMT	1500Nm/2400Nm,300/450kw	20136Nm
HTED22000	50-70T Heavy Truck	50-70T	4 Ratio AMT	1500Nm/2600Nm,280/420kw	21814Nm
HTED24000L	70-100T Heavy Truck	70-100T	4 Ratio AMT	1650Nm/2800Nm,315/510kw	24276Nm
HTED24000H	70-100T Heavy Truck	70-100T	4 Ratio AMT	1800Nm/2800Nm,360/550kw	24276Nm

Company Profile
Suzhou lvkon Transmission Technology Co., Ltd. is committed to developing into a leading driving product in the new energy vehicle industry, as well as a solution and service provider for vehicle power systems. The company was established in 2011 with a registered capital of 512.9 million yuan and covers an area of over 190 acres. It has now built a factory building of 10
0000 square meters. There are nearly 800 in-service employees, including 7 doctoral students, 54 master's students, and 50% of employees with a bachelor's degree or above; The core technical personnel are all from domestic 985 and 211 universities and high-end research institutions, and the main management team has rich experience in the research and development, production, and operation management of new energy vehicle power systems.
The main business of Green Control is the R&D, production and sales of AMT gearbox, new energy vehicle drive motor, pure electric and hybrid vehicle Powertrain. We have internationally advanced research and production equipment, and have achieved complete independent design and production capabilities for key components such as motors and gearboxes; The products cover passenger cars, sanitation, logistics vehicles, Dump truck, tractors, engineering machinery and other fields. There are both hybrid and pure electric vehicles, both motor direct drive, with reduction gearbox, with gearbox products, and also dual motor, electric drive axle products, basically meeting the needs of different types of new energy source commercial vehicles.
At present, green control products have been operated on nearly 60000 new energy vehicles in 14 countries overseas and over 300 cities in China, with a cumulative operating mileage of over 10 billion kilometers; Customers include more than 40 domestic bus enterprises, such as Zhongtong Bus, Foton Motor, Xiamen Jinlong, Xiamen Jinlv, Higer Bus, Sunlong Bus, and more than 20 truck enterprises, such as FAW, Dongfeng Motor, Sinotruk, Shaanxi Automobile, Jianghuai, Liuqi, Dayun, and Xugong. With industry-leading technological strength and a continuous drive for innovation, as well as a sincere attitude and professional level of serving customers, Green Control has won the trust of customers and gained widespread market recognition for its products.
Green Control's hybrid products have won honors such as the "Second Prize of the National Science and Technology Progress Award", and have served major events such as the "Hangzhou G20 Summit"; Since 2015, its market share in the commercial vehicle market has maintained over 30%. Green Control's pure electric products have an annual sales volume of over 15000 units; Received awards such as "Best Motor of New Energy Public Transport" and won three trophies in the Logistics Vehicle Challenge, including Best Climbing, Power Saving, and Range; At the grand and solemn "National Day 70th Anniversary Parade", half of the "Zero Squadron" sanitation cleaning and sweeping vehicles were equipped with green controlled pure electric assemblies.
In the future, Green Control's focus on new energy commercial vehicles remains unchanged, and will be committed to developing high-performance, low-cost products that can truly benefit users and create greater value for customers. Continuously improving methods, continuously improving enterprise management level, enhancing enterprise competitiveness, and becoming a world-class manufacturer of key automotive components is the development vision of Green Control; Pursuing excellence and contributing to society, Green Control will share technological achievements, drive the progress of upstream and downstream industries and competitors, and use technology to create a greener and better travel life for humanity!
Our Advantages
FAQ
Q1. How about your delivery time?
A: It will take 15 to 45days after receiving your advance payment. The specific delivery time depends on the items and the quantity of your order.
Q2. Can you produce according to the samples?
A: Yes, we can produce your samples or technical drawings. We can produce the molds and fixtures in-house.
Q3. What are your terms of payment?
A: T/T 40% as deposit, and 60% before delivery. We'll send you the photos of the products and packages before you pay the balance. For big orders, we accept L/C.
Q4. What are your terms of delivery?
A: FOB.
Q5. Do you test all your goods before delivery?
A: Yes, we have a 100% test before delivery, if necessary we can send an inspection report before delivery.
Q6. How long is your warranty period?
A: In general,2 years after deliveried
Q7. What are your terms of packing?
A: We pack our goods in neutral wooden boxes and paper cartons. If you have a legally registered brand, we can pack the goods in your branded boxes after getting your authorization letters.
Q8. Do you have any certificates?
A: SGS,IATF16949,ISO14001,ISO45001,Etc
Q9. Do you have the import & export license?
We are official import & export licensed manufacturer.

---
