Milano Roofing Shingle with Stone Coating Stone Chips Coated Roof Tile

Product Description

SPECIFICATIONS FOR STONE COATED STEEL ROOFING SHEETS
Name	Milano Roofing Shingle with Stone Coating Stone chips coated roof tile
Materials	Aluminum-zinc steel plate, colored stone chips
Product Size	1340*420mm/1300*420mm
Effective Size	1290*370mm/1250*370mm
Thickness	0.35mm, 0.4mm, 0.45mm, 0.5mm, 0.55mm
Weight	2.6-3.3kgs/pc
Coverage Area/Tile	0.48 / 0.46
Sheet/SQ.M	About 2.08/2.16 pieces
Long lifetime	50 years warranty Stone Coated Steel Roofing Sheet

Product Description
The Milano Roofing Shingle with Stone Coating, also known as Stone Chips Coated Roof Tile, is a high-quality roofing material designed to provide durability, aesthetic appeal, and long-lasting protection. Here's a breakdown of its key features:
1. Material Composition Base Material: Made from high-quality galvanized or aluminum-zinc (Aluzinc) steel, which provides excellent resistance to corrosion and extreme weather conditions. Stone Coating: The surface is coated with natural stone chips that enhance durability, weather resistance, and aesthetic appeal. Acrylic Resin Layer: A protective acrylic resin layer helps bind the stone coating and increases the lifespan of the tile. 2. Design & Aesthetic Appeal Milano Profile: Features a curved, smooth, and elegant design inspired by traditional Mediterranean roofing styles, giving a luxurious and stylish look. Variety of Colors: Available in multiple colors to match different architectural styles and customer preferences. Textured Surface: The stone-coated finish mimics the appearance of natural materials while offering superior durability. 3. Benefits & Features Durability: Resistant to extreme weather, including heavy rain, strong winds, and UV rays.
Lightweight: Lighter than traditional clay or concrete tiles, reducing structural load on the building.
Energy Efficiency: Reflects heat, helping to regulate indoor temperatures and improve energy efficiency.
Low Maintenance: Does not fade, crack, or break easily, reducing long-term maintenance costs.
Sound Insulation: Reduces noise from rain and external elements, providing a quieter indoor environment.
Eco-Friendly: Manufactured using recyclable materials, making it a sustainable roofing option.
SPECIFICATIONS FOR STONE COATED STEEL ROOFING SHEETS Specification Details

Product Name	Milano Roofing Shingle with Stone Coating (Stone Chips Coated Roof Tile)
Material Composition	Base Material: Aluminum-Zinc (Aluzinc) Steel Plate Coating: Natural Colored Stone Chips Protective Layer: Acrylic Resin Layer (UV & weather-resistant)
Product Dimensions	Standard Size: 1340mm × 420mm / 1300mm × 420mm
Effective Coverage	Usable Size: 1290mm × 370mm / 1250mm × 370mm
Thickness Options	0.35mm, 0.4mm, 0.45mm, 0.5mm, and 0.55mm
Weight Per Tile	2.6kg to 3.3kg per piece, depending on thickness
Coverage Area Per Tile	0.48 / 0.46, ensuring optimal coverage with fewer tiles
Sheets Per Square Meter	Approximately 2.08 to 2.16 pieces per , depending on installation method
Durability & Warranty	Lifespan: Over 50 years Warranty: Manufacturer's 50-year warranty on stone-coated steel roofing sheet

PHYSICAL & MECHANICAL PROPERTIES Parameter Details

Base Steel Type	High-strength Aluminum-Zinc (Aluzinc) Steel (55% Aluminum, 43.4% Zinc, 1.6% Silicon)
Steel Tensile Strength	≥ 550 MPa (High-Strength)
Steel Yield Strength	≥ 300 MPa
Steel Elongation	≥ 20%
Density	7.85 g/cm³
Impact Resistance	Withstands impact from hailstones up to 30mm in diameter
Fire Resistance	Class A Fire Rating (Non-combustible)
Wind Resistance	Up to 160 km/h (Hurricane-Resistant)
Water Absorption	< 0.2% (High Waterproof Performance)
Temperature Tolerance	-40°C to 85°C

CHEMICAL & ENVIRONMENTAL PROPERTIES Chemical Parameter Details

Coating Material	Colored Natural Stone Chips (Weather-resistant)
UV Resistance	High-performance UV protection against fading and discoloration
Corrosion Resistance	Strong anti-rust properties due to aluminum-zinc alloy layer
Acid & Alkali Resistance	Resistant to acidic rain, salt spray, and industrial pollution
Thermal Reflectivity	High reflectivity reduces heat absorption, improving energy efficiency
Eco-Friendly Rating	100% Recyclable Material

WORKCRAFT DETAILS & MANUFACTURING PROCESS Process Description

Steel Preparation	High-strength Aluzinc steel is rolled and cut to required dimensions
Surface Treatment	Anti-corrosion treatment applied to enhance durability
Base Coating	Epoxy primer coating applied for adhesion and protection
Stone Chips Application	Natural stone chips embedded using high-bond acrylic resin
Baking & Curing	Heated in an industrial oven for strong adhesion and enhanced weather resistance
Final Coating	UV-resistant protective acrylic coating applied for longevity
Quality Control	Rigorous tests for thickness, strength, coating adhesion, and weather resistance

Features 1. Economic Due to its light weight and large size, it usually takes 3-5 days for 2 workers to complete all the installation in a common residence. And it greatly reduces related costs in transport as well as application. 2. Easily installed Lightness and easy-to-cut determine that it is widely used in various buildings, like steep roofs or high-rise building. Scientific and reasonable design make it much easier to install. 3. Wind resistance and storm resistance Stone coated metal roof tile has only 1/6 of the weight of other traditional tiles, but the horizontal overlap design of each piece can resist cyclone and strong wind. 4. Heat insulation and durability Alu-zinc steel plate has strong heat resistance, and stone chips coated design also insulates from heat when exposed to ultraviolet radiation. In addition, the lifespan of stone coated metal tile can be up to 50 years.
Raw material
GALVALUME STEEL Coating composition is 55% aluminum in weight ratio (80% surface volume ratio), 43.4% zinc, and 1.6% silicon. STONE CHIPS All Forsetra® roof tiles are coated with natural stone chips, volcanically formed and taken from quarries in French and the most famous Chinese-brand of CG Rock only. We don't use any other fake stone chips from other factories which are cheap but lousy quality.
Products applications
Residential homes Villas and mansions Commercial buildings Resorts and hotels Public and institutional buildings Would you like more details on installation or pricing?
Our main products Bond Tile
Bond Tile is one of the original innovations in roofing materials. Combining lightness with strength and durability, this tile features a distinctive round bead sliding appearance with smooth curves. Its concave and convex design effectively guides water, making it a popular choice in the market. The novel structure and aesthetic appeal lay a solid foundation for the development and promotion of modern architecture, enhancing both the functionality and beauty of any building.
Milano Tile
Milano Tile offers elegance and versatility, with its smooth curves and refined finish. This tile integrates seamlessly into a variety of architectural designs, adding a sense of order and sophistication. The carefully crafted shape and unique color variations bring a distinct touch of class to roofing projects, elevating the overall aesthetic of a structure.
Makuti Grained Tile (Wood Shake Tile)
The Makuti Grained Tile imitates the natural texture of wood while offering the strength and protection of metal. With its coarse, grainy texture that resembles rough-hewn wood, this tile serves as an eco-friendly option by reducing the need for natural wood. It combines the beauty of wood with the durability of metal, creating a harmonious balance between different materials for a truly unique roofing solution.
Arris Tile (Classic Tile)
Arris Tile offers a traditional yet durable roofing solution with its classic design. Featuring subtle variations in pattern, it provides a sense of stability and security beneath the roof. This tile is ideal for those seeking a timeless aesthetic, combining classic elegance with robust functionality for a reliable roofing option.
Rainbow Tile
Rainbow Tile is a vibrant, colored stone tile that brings character and personality to any roofing project. Its unique hues and striking design make it a standout choice for builders looking to make a bold statement while maintaining structural integrity and long-term durability.
Shingle Tile
Shingle Tile is a postmodern design featuring angular lines and a concave-convex curve. Designed for efficiency, it suppresses grid modules and enhances the overall performance of a roofing system. Its streamlined design provides both an aesthetically pleasing look and improved functionality, making it a reliable choice for contemporary architecture.
Tudor Tile
Inspired by traditional English architecture, Tudor Tile replicates the distinct charm of classic Tudor-style homes. It features a deep profile with a structured, overlapping design that enhances the roof's visual depth while ensuring superior water drainage. Its strong, lightweight metal structure offers a long-lasting roofing solution with an old-world charm.
Big Roman Tile
Big Roman Tile is an architectural masterpiece that embodies grandeur and sophistication. With its large, flowing curves and bold profile, this tile is designed to complement high-end residential and commercial buildings. Its wave-like design not only adds to its striking visual appeal but also improves water drainage and wind resistance, making it a highly functional and stylish roofing solution.


Related Products Production process
What We Can Offer 1) Quality Products We provide the 50 years warranty letter for you. Never bring any trouble and complaint after you sell. Make your choice without any worry. 2) Competitive Price Factory direct-sell, no middlemen to earn price difference. Same Quality, Best Price. Same Price, Best Quality. 3) Clients Require information We can recommend the end-clients information to our importer customers, increase importers selling speed and sales volume. 4) Delivery Time Two roof tile factories, 10-15 days delivery, meet our customers fast delivery time request. 5) Relate Products PVC rain water collector is the relate products of roof tile. The rest of container space after load roof tile,we will suggest our customers to load rain water collector and make the container full full. Save total cost.
Our company introduction---professional manufacturer of roofing tiles with stone coating
Hangzhou Forsetra Roof Tile Co.,Ltd is specializing in roofing construction system product research and development, production, sales, and provide customers with professional roofing building system solutions. Company's main stone coated metal tiles, metal water system, PVC water system, and can customize according to customer's demands. Dedicated to the service of high-end villas terrace house project, build quality art of living space.

---
