Biomass Pellet Machine Wood Pellet Machine The Latest Drop Material Ring Mold Biomass Sawdust Wood Pellet Machine

Product Description

Biomass Wood Pellet Machine is our competitive products. We are specialized in designing and manufacturing biomass pellet machinery and the complete production line (all auxiliary equipment) with advanced technology. Applications of Wood Pellet Production Line: It is mainly used for agro-forestry residues ,such as straw ,cotton stalk , rice husk, peanut shell ,bamboo,empty fruit branch,pulverized coal and waste paper etc. The refined stainless steel mold used in our machine ensures a longer service life, several times that of ordinary products. With its double-layer design, the mold can be used twice, providing excellent durability. The transmission structure is automatically lubricated and protected by the circulating pump, ensuring smooth operation and protecting the bearing.
Our wood pellet production line boasts low energy consumption, high efficiency, and exceptional durability. We take pride in producing all the accessories and components in-house, eliminating any quality control problems that may arise from outsourcing.

Model	Power (kw)	Capacity(kgs/h)	Weight(kgs)	Dimension(mm)
JN560	90+1.5+0.37+1.5	1000-1200	4200	2300x1250x1950
JN560P	110+1.5+0.37+1.5	1200-1500	4500	2300x1250x1950
JN560X	132+1.5+0.37+1.5	1500-2000	5000	2300x1250x1950
JN700	160+1.5+0.37+1.5	1500-2000	6200	2800x1400x2100
JN850	220+3+0.37(0.55)+2.2	2000-3000	14500	3200x1630x2300

How to Make Pellets
Use a Wood Chipper or Wood Crusher to break down wood logs, chips, or other materials into smaller pieces.
Use a Dryer, such as a rotary drum dryer or air-flow dryer, to reduce the moisture content of the sawdust or other materials to between 8-15%. This moisture content is ideal for pelletizing.
Gradually feed the sawdust or materials into the pellet machine. For large-scale pellet production, a screw feeder is recommended to ensure a stable feeding of raw materials.
After pelletizing, the pellets are hot and cannot be directly packed. They need to be cooled using a pellet cooler.
Next, the pellets go through a vibrating sieve. Good pellets will be separated, while broken ones or powder will be collected for reproduction.
Finally, the pellets can be packed using a pellet packing machine
Scope Of UseRing mold granule machine, widely used in large, medium and small aquaculture, food feed processing plants, livestock farms, poultry farms, individual farmers and small and medium-sized farms, farmers or large, medium and small feed processing plants. Ring mold particle machine is also a kind of particle equipment commonly used in the biomass energy industry is the biomass raw materials such as: branches, stalks, crushed into rod particles, fuel molding equipment to replace coal.
Product use Vertical ring die granulator is a machine for developing dry powder into required particles. According to its use, it can be divided into feed granule machine, wood pellet machine, straw scale pellet machine, rice husk pellet machine, sawdust pellet machine, fuel pellet machine, biomass pellet machine, fertilizer pellet machine, organic fertilizer pellet machine and so on.
Product Mix
The mold is vertical and double layered, with dual use of upper and lower layers, improving utilization, reducing costs, and increasing efficiency.
The pressure wheel rotates, the material is centrifuged, and the surrounding material is evenly distributed.
Efficient and energy-saving, automatic timed oil lubrication, ensuring sufficient lubrication of bearings and safer and more reliable operation.

---
