| SER | ITEM | PARAMETER | UNIT | DATA | REMARK |
| 1 | WHOLE VEHICLE | VEHICLE MODEL | JSIEW5250ZYSQ | ||
| MANUFACTURE DATE | 2019 | ||||
| OVERALL DEMENSION | MM | 10300×2500×3300 | |||
| GVW | KG | 25000 | |||
| CURB WEIGHT | KG | 13000 | |||
| MAX GRADABILITY WHEN FULL LOADING | DEG | 32° | |||
| MAX SPEED | KM/H | 85 | |||
| FRONT/REAR HANGING | MM | 1250/3050 | |||
| CLOSE/DEPARTURE ANGLE | DEG | 20/12 | |||
| LEAF SPRING | PCS | 9/10 | |||
| DRIVE WHEEL | 6*4 | ||||
| 2 | CHASSIS | CHASSIS MODEL | QL1250DPFZY (I suzu ) | ||
| MANUFACTURER | I suzu Motors Co.,Ltd. | ||||
| MANUFACTURE DATE | 2019 | ||||
| ABS | Equipped | ||||
| POWER STEERING | Equipped | ||||
| FRONT AXLE | 7T | ||||
| REAR AXLE | 18T | ||||
| WHEELBASE | 4000+1300 | ||||
| TYRE SPECIFICATION | 10.00-20 | ||||
| NO OF TYRES | PCS | 10+1 spare tyre | |||
| 3 | ENGINE | ENGINE MODEL | 6HK1-TCSG40 | ||
| MANUFACTER | I suzu Diesel Motors Co.,Ltd. | ||||
| ENGINE POWER | KW | 206 | |||
| ENGINE HORSEPOWER | PS | 280 | |||
| DISPLACEMENT | ML | 7790 | |||
| EMISSION STANDARD | Euro IV | ||||
| ENGINE DETAILS MORE | 6 CYCLINDERS | ||||
| ELECTRICICAL INJECTION | |||||
| WATERCOOLED TURBOCHARGE | |||||
| 4 | GEARBOX | NO OF GEARS | 9 forward gears and 1 reverse | ||
| MODEL | 9JS119TA | ||||
| RATIO | 12.57/ 7.47/5.28/3.82/2.79/1.95/1.38/ 1/0.73/R13.14 | ||||
| 5 | GARBAGE | BRAND | JSIE | ||
| MANUFACTER | Xiamen Justsun Intelligent Co.,Ltd. | ||||
| BASIC CONFIGURATION | Hydraulic system, operating system, lifting system, oil tank, cabinet door pendulum, hanging barrels institutions etc. | ||||
| COMPRESS SYSTEM | Circuit control system, pneumatic valve control cylinder, cylinder operating multiple valves, hydraulic multi-way valve control cylinder | ||||
| HYDRAULIC SYSTEM | Tank and filtration system, pumps, multi-valve, fuel tank, tubing and other components, the system power from the engine, power take off down the separation of power, the power take off driven gear pump | ||||
| THICHNESS OF FLAT | MM | 6 | |||
| VOLUME | M3 | 8 | |||
| HOPPER CAPACITY | M3 | 1.5 | |||
| MATERAIL | Carbon steel | ||||
| 6 | CAB | MODEL | I suzu FVZ | ||
| SEATS | 3 | ||||
| COLOR | According to you | ||||
| A/C | Equipped | ||||
| OTHERS | With FM RADIO,Spare tire stents and so on | ||||
