Automatic Horizontal Shenzhou Bottle Cap Making Plastic Injection Molding Machine

Product Description

ITEM	UNIT	SZ-2000A
INJECTION UNIT
SCREW DIAMETER	mm	50	55	60
SCREW LID RATIO	L/D	23.1	21	19.3
THEORETICAL SHOT VOLUME	CM3	491	594	707
SHOT WEIGHT(PS)	g	447	540	643
INJECTION PRESSURE	Mpa	215	178	149
THEORETICAL INJECTION RATE(PS)	g/s	145	175	208
PLASTICISING CAPACITY	g/s	22.5	28.7	35.4
SCREW TORQUE	N.m	1510
MAX.SCREW ROTATE SPEED	r/min	170
INJECTION STROKE	mm	250
CLAMPING UNIT
MAX.CLAMPING FORCE K	KN	2000
MAX.OPENING STROKE	mm	500
SPACE BETWEEN TIE BARS	mm	505×505
MOULD HEIGHT	mm	190-530
MAX.DAYLIGHT	mm	1030
EJECTOR FORCE	KN	53.1
EJECTOR STROKE	mm	125
EJECTOR QUANTITY		5
OTHER
PUMP MOTOR POWER	KW	18.5
PUMP PRESSURE	Mpa	16
HEATING POWER	KW	16.6
HEATING ZONE		4
SIZE	m	5.9×1.5×2
NET WEIGHT	t	6.8
OIL TANK CAPACITY	L	420
INTERNATIONAL DESIGNATION		2000-1060

Q1: All of your products are made by yourself or purchasing the others?
We have independent technical team who focus on making machines, all the products
are made by our technical team.
Q2: What is the ability of your factory?
About injection molding machine, we could produce 50 sets machines per month.
about blow molding machine, we could produce 30sets machine per month
Q3: Do you have any technical supports about your products?
We have had long term collaboration with our partners worldwide, and we have a lot
of cooperation with a lot hef advanced manufacture company on the world.
Q4: Does the machine have an English manual and warranty card?
Each machine has a professional English operation manual and warranty card.
In addition, we can provide electronic version of the English manual.
Q5: Do you have an aftermarket warranty for your products?
Warranty: General one year for whole injection molding machines.
General one year for other types of whole machines.
All customers that have bought SHENZHOU injection molding machines would be provided with a lifetime repair service of the machines.
Q6: Who is responsible for the installation and debugging of the machine I purchased?
We the seller are fully responsible to send our engineers within two weeks from the date of the containers arrival to the buyers factory to commissioning the machine and training the staff of the buyer, the buyer should be responsible for a round trip economy ticket, a hotel and any other necessary accommodations for the seller's engineers, and engineer cost USD 80.00 per day.

---
