High-Capacity Environmental Protection Customizable Innovative Dayun 4X2 Chassis 8 Cubic with High Mobility Hook Arm for Municipal Services Garbage Truck

Product Description

The kitchen garbage truck, also known as the slop truckis primarily used for the collection and transportation of kitchen organicwaste.lt features a high level of automation for waste loading andunloading,reliable operation, good sealing performance, large loadingcapacity,easy operation, and a closed transportation process thatprevents sewage leakage and the emission of unpleasant odors. lt isenvironmentally friendly, The vehicle can be equipped with standardgarbage bins of different sizes, making it highly versatile. The kitchen garbage truck is an efficient and clean specialized vehicle forthe collection and transportation of kitchen organic waste.The operation of a kitchen garbage truck involves the gradual loadingof bucketed "slop" onto a conveyor belt within the vehicle, which is then poured intothe cargo compartment (consisting of a body and a tank) from the top, The depositedwaste is forcefully compressed by a strong push plate, followed by solid-liquidseparation. The separated liquid flows into the sewage tank at the bottom of the tank.while the solid waste is compressed and stored within the tank, reducing its volume.Once the tank is filled, the vehicle transports the waste to a kitchen waste resourceoptimization treatment plant. The entire process is automated.The collection and centralized treatment of kitchen waste require not only post-treatment equipment for harmless and resourceful processing but also specializedvehicles for collection and transportation. Due to the high moisture content andcomplex composition of kitchen waste, the vehicles need to have good sealing, easyand safe operation, high and convenient loading and unloading efficiency, andcompatibility with subsequent resourceful equipment.

Overall dimensions	5480,5575,5625×2075,2095×2080, 2100,2180,2200,2250,2350(mm)	Rated load capacity	500(Kg)
Gross Vehicle Weight	4490(Kg)	ABS	standard configuration
Curb weight(kg)	3860(Kg)	Front/rear suspension	1130/1050,1155/1045, 1150/1050,1180/1020(mm)
Approach/departure angle	19/21,15/21(°)	Front and rear Axle Load	1600/2890
Wheelbase	3300(mm)	Number of axles	2
Maximum speed	89Km/h	Number of spring pieces	3/3+3,4/3+3,4/6+4,9/9+6, 1/1+1,3/5+3,5/6+5,4/5+3, 1/1,4/9+6,4/11+8,8/9+4, 9/11+8,6/5+3,6/9+6,2/3+2, 3/3+2,3/4+3,3/5,4/4+3
Number of tires	6	Tire Size	7.00R16LT 8PR
Front track	1595(mm)	Rear track	1640(mm)
volume	8m³	Transmission	wanliyang 6 Speed gearbox
Engine model	YN25PLUS1	Power (kw)/horsepower (PS)	143ps
Fuel	Diesel
Other
The vehicle is used for garbage transfer, the main special device consists of hydraulic system and lifting arm; optional rear locking device style, optional rear hydraulic leg, optional hook arm structure and hand control valve. ABS model: CM4XL-4S / 4M, VIE ABS-II, 3550X-1010; ABS manufacturer: Guangzhou Ricomi Automotive Electronics Co., Ltd., Zhejiang Wan'an Technology Co., Ltd., East Cockor Commercial Vehicle Brake System (Shiyan) Co., Ltd.; 1640. With the chassis optional sunshade, front panel, front lamps and front bumper style, With the chassis optional tire steel ring color, the rear beam style of the optional frame, The model is equipped with ETC vehicle device; The corresponding relationship between engine / fuel consumption value (L / 100km) is D20TCIF11 / 11.1; D25TCIF1/11.1; YCY24140-60/11.1; YN25PLUS1/10.1; . Side rear protection: side and rear protective device materials are Q235, side protection welding + bolt connection; rear protection welding + bolt connection, rear protection height is 450mm, section height and thickness are 120mm 60mm; correspondence of vehicle length size: 5480=1130 + 3300 + 1050,5575=1225 + 3300 + 1050,5625=1225 + 3300 + 1100. Preparation quality excluding spare tire, fire extinguisher and vehicle tools.

---
