| US$9,700.00-12,500.00 | 1 Piece (MOQ) |
| ITEM | UNIT | T35 | |
| General Rules | CNC system | GSK | |
| physical dimension | mm | 2100*1450*1850 | |
| Total weight of machine tool | kg | 1500 | |
| Height of the center of the spindle of the bed bottom cutter | mm | 990 | |
| The scope of work | Maximum rotation diameter on the bed | mm | φ400 |
| Rotation diameter on tool holder bottom plate | mm | φ120 | |
| X-axis maximum travel | mm | 680 | |
| Z axis maximum travel | mm | 400 | |
| Maximum processing length | mm | φ400 | |
| Spindle | Workpiece clamping method | Spring chuck | |
| Spindle speed | rpm | 100-3000 | |
| Spindle end | A2-5 | ||
| Spindle through hole diameter | mm | φ400 | |
| Working accuracy | Servo main motor power | kw | 4 |
| X/Z repeat positioning accuracy | mm | 0.003 | |
| X-axis fast forward speed | m/min | 24 | |
| Z-axis fast forward speed | m/min | 24 | |
| X-axis movement | mm | 800 | |
| Z axis movement | mm | 420 | |
| Tool holder | Tool holder form | Row knife | |
| Knife square size | mm | 20*20 | |
| Maximum number of blades | pcs | 9 | |
