1000L Mobile Fire Fighting Foam Trailer with Mounted Monitor

Product Description

1000L Mobile Fire Fighting Foam Trailer with Mounted Monitor
Product description
The SINOFIRE PLKD30T trailer mounted monitor is specially designed for today's industrial firefighting and protection needs. It can be used for fire-fighting, cooling, personnel protection, gas evacuation, etc. This fire monitor has two types: water and foam. They both have large water and foam flow, so they can extinguish the fire faster than similar products. The operator can control and operate it in both horizontal and vertical directions.
Pictures

1.Hand brake and towing	11. Non slip decking
2.Frame and accessories painted YELLOW color	12.Restraining straps and mounting platform for IBC
3.Manual jockey wheel	13.1000 litre IBC foam container with foam resistant plastic body
4.Drain valve	14.PLKD32 Fire monitor 4 Drain valve 5 D-rings
5.D-rings	15.Gate valve DN80 6 Pressure Gage
6.Pressure Gage	16.Foam suction hose and connection to self inducing monitor 7 Water inlet single 80mm (3")Storz coupling
7.Water inlet single 80mm (3")Storz coupling	17.Mudguards
8.Manual stabilization jacks with folding handles	18.Pneumatic Tyre
9.Foam inductor	19.Road going lights at rear
10.Outlet valve	20.Slide bar

Parameter

Water Trailer
Water flow	1000L/s
Effective jetting rate	1000kg/s
Jetting pressure	25MPa
Jetting range	200m
Pitching angle	-45°~+90°
Rotation angle	180°
Max spray angle	180°
Voltage	220V
Power	220kW
Weight	1000-5000kg
Foam Trailer
Model	SX-FT
Capacity	1000L
Mixing ratio	0.5% ~ 1% ~ 3%
Slide device	4pcs
Outer size(LxWxH)	4000×2300×1800mm(Approx)
Gross weight (not include the foam)	2 tons(Approx)
Material of foam tank	Carbon steel
Material of foam gun	Stainless steel
Package	Liquid level display tube, tool kit, safety rails railing, wear-resisting mat, reflective labeling

ITEMS FOR ODM- CUSTOMIZED
SINOFIRE Foam trailer accept to design based on customer's requirements. 1. Frame Size: 4000mm*2300mm*1800mm ( Standard ). Size Customized.2. Frame Color: Yellow RAL 1023 ( Standard ). Color Customized.3. Fire Monitor Mounted: 1 set ( Standard ). 2 sets ( Customized ).4. Outlet Pipe Line: Monitor outlet (one), foam outlet (one), water outlet (one).( Standard ). Accept customized for outlet quantity,type and size.5. Foam Concentrate Container: 1 set 1000 Liter ( IBC )(Standard). Container capacity and quantity Customized. * If you have others want to customized, just contact us for further discuss. Highly welcome different ideas from you . * Before order, please contact us to make sure all the details and final quotation.
