| US$125.00-150.00 | 1 Piece (MOQ) |
| Specification parameters | Unit | P20 | P16 | P10 | P8 | P6 | P4 |
| Pixel Density | Dot/m² | 2500 | 3906 | 10000 | 15625 | 27778 | 62500 |
| LED devices | / | WE2121RGB-IC | WE2121RGB-IC | WE1314RGB-IC | WE1314RGB-IC | WE1314RGB-IC | WE1314RGB-IC |
| Module Size | mm | 240*960 | 240*960 | 240*960 | 240*960 | 240*960 | 240*960 |
| Module Pixel | / | 12*48 | 15*60 | 24*96 | 30*120 | 40*160 | 60*240 |
| Weight | Kg/m² | <3kg/ | <3kg/ | <3kg/ | <3kg/ | <3kg/ | <3kg/ |
| White balance brightness | Cd/m² | 2000/4000 | 2000/4000 | 2000/4000 | 2000/4000 | 2000/4000 | 2000/4000 |
| Permeability | % | 95 | 94 | 93 | 92 | 90 | 87 |
| Optimal Sight Distance | m | >=20 | >= 16 | >= 10 | >=8 | >=6 | >=4 |
| Viewing Angle | Angle | 160 | 160 | 160 | 160 | 160 | 160 |
| Operating Voltage | / | DC 5V | DC 5V | DC 5V | DC 5V | DC 5V | DC 5V |
| Input Voltage | / | AC200-240V | AC200-240V | AC200-240V | AC200-240V | AC200-240V | AC200-240V |
| Average power consumption | W/m² | 80 | 80 | 150 | 150 | 200 | 200 |
| Maximum power consumption | W/m² | 200 | 200 | 400 | 400 | 600 | 600 |
| Installation method | / | Hoisting/affixed | Hoisting/affixed | Hoisting/affixed | Hoisting/affixed | Hoisting/affixed | Hoisting/affixed |
| Brightness control level | / | 256 | 256 | 256 | 256 | 256 | 256 |
| ayscale level | bit | 16bit | 16bit | 16bit | 16bit | 16bit | 16bit |
| Operating temperature | ºC | -20~ +65 | -20~ +65 | -20~ +65 | -20~ +65 | -20~ +65 | -20~ +65 |
| Working humidity | / | 10-65%RH | 10-65%RH | 10-65%RH | 10-65%RH | 10-65%RH | 10-65%RH |
| Typical Lifespan | H | 100000 hours | 100000 hours | 100000 hours | 100000 hours | 100000 hours | 100000 hours |
| control system | / | Mosier/Nova/Carlette | |||||
