Zoomlion 14ton Hydraulic Crawler Excavator Ze135e-10 for Sale

Product Description

ZOOMLION 14ton hydraulic crawler excavator ZE135E-10 for sale
External structure
Auroragreen coloring, always catch your eyes
Renewal and upgrade Auroragreen painting and classical modular covering create an eye-catching visual impact.
Reinforced Boom
The strengthened and thickened key stress points of Boom and large section structure design can make the Boom withstand the tremendous pressure brought by the construction effortlessly.
Low-resistance and large- capacity bucket
In order to find the best cutting angle of the bucket in the excavation process, we conducted many excavation simulations and developed the D-ARCS low-resistance and large- capacity bucket. Besides, NM400 wear-resistant steel plate is selected to improve the bucket life and comprehensive fuel consumption.
Reinforced undercarriage
The thickness of the plate for the key wear parts has been increased and the imported wear-resistant steel plate is adopted. The X -frame and Track roller design has increased the stability and durability of the product greatly.
Keep a closed and comfortable driving space in the noisy construction site
Large display with new man-machine interactive operating system and rich functions is simple and easy to use; radio, USB and other entertainment functions are all equipped. Optimized HVAC blower and assembly art enhanced the closeness and comfort of the cab greatly.
Endless exploration for energy saving and low consumption
Advanced electrical control system and optimized power matching lowered the fuel consumption rate and significantly improved operation efficiency and fuel efficiency. Besides, the three work modes can be matched optimizedly according to working conditions, which improves the operation efficiency and saves energy at the same time.
One-stop maintenance design
All maintenance can be completed from the ground. Centralized distribution of maintenance points shortened the maintenance time. The special hydraulic oil can prolong the service life greatly and save more than 50% of the maintenance cost for users.
Centralized layout to make the machine-checking comfortable

Items	Unit	Value
Model	Operating mass		14000
	Standard bucket capacity	m3	0.55
Performance	Swing speed	r/min	12
	Travel speed (high / low)	km/h	3.0/5.3
	Maximum drawbar pull	kN	123
	Bucket digging force(ISO)	kN	96
	Arm digging force(ISO)	kN	71
Engine	Engine manufacturer	-	CUMMINS
	Rated power	kw/rpm	86/2200
	Displacement	L	3.8
	Emission	-	China stage3
Dimensions	Total length	mm	8090
	Total width	mm	2580
	Total height	mm	2900
	Tail swing radius	mm	2320
	Track gauge	mm	2000
	Track length on ground	mm	3005
Work range	Max. digging reach	mm	8540
	Max. digging reach at ground level	mm	8415
	Max. digging depth	mm	5495
	Max. digging height	mm	8690
	Max. dumping height	mm	6055

---
