1ton 2ton 3ton 5ton Electric Wire Rope Stainless Steel Drum Prop Pulling Winch

Product Description

Introduction of 1Ton 2Ton 3Ton 5Ton Electric Wire Rope Stainless Steel Drum Prop Pulling Winch prop pulling winch adopts spherical worm gear vice drive, with compact structure, small size, can be the whole machine down the well, the winch structure is symmetrical, is long, the base is sled-shaped, in the well since moving smoothly and easily; winch low center of gravity, base rigidity is good, not only can play the top column, but also can be installed ground anchor, so easy to install, stable operation, safe and reliable.zmwm02
Parameter of 1Ton 2Ton 3Ton 5Ton Electric Wire Rope Stainless Steel Drum Prop Pulling Winch

Model Parameter		JH-5	JH-8	JH-14	JH-20	JH-30
Steel wire rope average static tension (KN)		50	80	140	200	300
Steel wire rope (m/s) average speed		0.17	0.12	0.115	0.118	0.13
Drum	diameter*width (mm)	276* 372	280* 230	400* 317	430* 530	550*560
	rope capacity (m)	80	100	130	170	220
Steel wire rope	diameter	15.5	17	21.5	24.5	30
	construction	6* 19	6* 19	6* 19	6* 19	6* 19
	nominal extension strength (Mpa)	1550	1550	1550	1550	1570
Explosion proof motor	Model	YBJ7.5-4	YBK2-160M-6	YBK2-200L1-6	YBK2-200L2-6	YBK2-280S-4
	Power (KW)	7.5	7.5	18.5	22	45
	Voltage (V)	380/660	380/660	380/660	380/660	380/660
	Rotate speed (r/min)	1450	970	970	970	980
Overall size: L* W* H		1450*512*515	1550*530*570	1955*680*815	2560*968*797	3300*1077*1034
Winch weight (including motor)		620	650	1350	2600	4460

Pictures of 1Ton 2Ton 3Ton 5Ton Electric Wire Rope Stainless Steel Drum Prop Pulling Winch

---
