Jtmt Ck61125 Hard Rail Flat Bed High Precision CNC Machine Tool Engraving Milling Longmen Machining Center

Product Description

We have 50 years of professional experience in the production of numerical control machine tools. The industrial park covers an area of 66,000 square meters and the construction area is 15,000 square meters. For professional services, please consult customer service.
Product Description

1.The main shaft is supported by high-quality, high-precision, group bearings and three-point support structure. The main shaft is a three-speed variable frequency speed control system.
2.The lathe is driven by precision ball screw
3.Semi-protection, super-audio frequency quenching and fine grinding of the bed guide rail, and fully plastic sliding guide rail.
4.The tool holder is a four-station tool holder.
5.The follow-up operation box is convenient for knife setting. Double door protection, good waterproof performance.
6.The follow-up operation box is convenient for knife setting. Double door protection, good waterproof performance.
Product Parameters

Item	Unit	CK61125Q	CK61125
Maximum turning diameter on the bed	mm	1250	Φ1250
Maximum turning diameter on sliding plate	mm	Φ850	Φ850
Distance between centers	mm	1500,3000	1500,3000
Width of bed guide rail	mm	660	755
Maximum travel of X axis/Z axis	mm	530/1500,3050	600/1500,3000
X-axis/Z-axis fast moving speed	m/min	3/5	3/4
Spindle speed range (stepless)	r.p.m	Third gear, stepless 18-600	Fourth gear, stepless in gear, 5-400r/min
Spindle head/spindle taper hole/spindle through-hole diameter	mm	C11/Φ140 1:20/Φ130	A2-15 /Φ140 1:20/Φ130
Chuck form and specification (Puka)	mm	Φ800	Φ800
Maximum tool size	mm	40×40	40×40
ool carrier		Four-position electric tool holder	Four-position electric tool holder
Minimum feed increment	mm	0.001	0.001
Repetitive positioning accuracy X/Z	mm	0.01/0.015	0.01 /0.015
Diameter/stroke of tailstock sleeve	mm	Φ100/250	ø 160/300
Tailstock sleeve taper hole		MT6#	MT6#
Main motor power	Kw	15	22
Machine size (length × wide × High)	mm	3650/5200×1900×1800	3700,5300×2400×2100
Machine weight	Kg	6100,7100	9000,11000

Certifications

FAQ
Q.What are your normal lead times?
A.Our company typical lead times range from 3-20days after receipt of order.
Q.What are the terms of payments you offer?
A.We accept payment of T/T, L/C, and Western Union, cash, OlA etc.
Q.what kind of package do you offer?
A.Normally in plywood case, to make sure all goods in good condition.
Q.What is the MOQ for your production?
A.The MOQ depends on your requirements for color, logo and so on.For some normal items, we have in stock, the MOQ is 1 set.
Q.Do you have CE certification?
A.Yes, we have CE certification, machine quality is one year guaranteed.
Q.How to control the quality of the products?
A.We have always placed great emphasis on the quality level is maintained.Moreover,the principle we always maintain is "to provide
customers better quality, better price,and better service".

---
