HAWKER BATTERY AX12-45 12V45Ah AGV
Detailed description
Mobile machines, including all kinds of mobile intelligent robots and AGV vehicles,the power of its own source is the battery. In order to ensure that the mobile machinery can be continuous, stable, safe and reliable work, reasonable configuration of power supply, choose to use high efficiency, and low cost battery, it is very important.
Hawker Power Group Limited is the world's most advanced power supply manufacturer. To meet the requirements of emerging applications, with its advanced manufacturing equipment and processes, the latest patented technology and materials, designed for mobile mechanical power supply adsorption (AGM) AX series maintenance-free lead-acid sealed batteries. The series of batteries in strict compliance with the international standard battery production, not only to strengthen the deep cycle discharge and fast charge capacity, but also improve the use of security and reliability, no damage to equipment and the environment, no pollution.
Follow the standard
● Product design in line with international standards IEC 60896 / 21-22
● In accordance with the Eurobat guidelines issued in 1999, this series of products belong to the "long life" category
● Complies with Telcordia SR-4228
● UL certification (UL standard 1989)
● According to the US "DOT Regulation 49" and the ICAO ICAO and IATA "Packaging Directive 806", it was approved as a non-dangerous goods suitable for land, sea and air transport
● certified by ISO 9001: 2000 and ISO 14001: 2004 certified Hawker factory production
Specifications and technical specifications
Types
parameter
| AGM (Adsorption) AX Series
|
AX12-18
| AX12-26
| AX12-33
| AX12-45
| AX12-60
| AX12-75
| AX12-100
| AX12-120
| AX12-150
| AX12-180
| AX12-200
|
Single voltage
| 12V
|
Rated Capacity
（25℃）
| 18AH
| 26AH
| 33AH
| 45Ah
| 60Ah
| 75Ah
| 100Ah
| 120AH
| 150AH
| 180AH
| 200AH
|
Internal resistance(mΩ)
| 10.0
| 8.0
| 9.0
| 7.0
| 6.5
| 6.0
| 5.0
| 4.5
| 4.0
| 4.0
| 3.8
|
Single
size
| Length
(mm)
| 181
| 166
| 195
| 198
| 260
| 260
| 308
| 408
| 485
| 530
| 522
|
width
(mm)
| 77
| 175
| 130
| 166
| 170
| 170
| 170
| 177
| 170
| 210
| 240
|
height
(mm)
| 168
| 125
| 180
| 170
| 185
| 235
| 215
| 225
| 240
| 215
| 225
|
weight (kg)
| 5.9
| 9.0
| 10.2
| 14.6
| 20.2
| 23.5
| 30
| 36.5
| 47.0
| 53.0
| 63.0
|
Short circuit current
(A)
| 900
| 900
| 1150
| 1250
| 1450
| 1750
| 2300
| 2420
| 2950
| 3350
| 3750
|
Maximum discharge
Current(A)
| 180
| 260
| 330
| 450
| 600
| 765
| 1025
| 1200
| 1510
| 1850
| 2100
|
Maximum charge current(A)
| 3.6
| 5.2
| 6.6
| 9
| 12
| 15
| 20
| 24
| 30
| 36
| 40
|
Charging voltage：Temperature: 25 ℃, float: 13.62V; fast charge: 14.2V
proper temperature：-10℃～40℃
Recommended temperature: 20 ℃ ~ 25 ℃
Number of deep cycle discharges：More than 1200 times 50% DOD; more than 800 times 80% DOD
|
Terminal
| M5
| M5
| M6
| M6
| M6
| M6
| M8
| M8
| M8
| M8
|
|
Introduction
Hawker HuaDa EV series of power battery, is the international advanced level of lithium iron phosphate (LiFePO4) power battery system. With high energy density, long cycle life, excellent charge and discharge performance, good temperature performance, is a new generation of high security and high reliability of the green power supply.
This series of batteries is the use of the latest development of the battery management system (BMS), specifically for mobile mechanical equipment, online charging and wireless charging and design and production of power batteries, with advanced battery self-management, communication, alarm and short-term fast charge Complete function.
Product Features
● Excellent charge and discharge overvoltage and undervoltage protection
● provide analog output AO, SOC analog output 0 ~ 5V, user-friendly power monitoring
Note: SOC can only be used as a reference, can not be used as a decision.
● Provides a highly efficient passive equalization system
● Charge / discharge are all with short circuit insurance
● Panel LED power, system status display
● Rich interface, through the digital IO and 485 interface to achieve information exchange
● professional industrial design and material selection, sustainable work in the harsh industrial environment
● support high-power charge and discharge, to meet the needs of a variety of different industrial conditions
● wide temperature working environment conditions, -20 degrees -60 degrees
● small size
Dimensions specifications
Types
| Battery size
Long*wide*high（mm）
| Charge continuous current
| Discharge continuous current
|
EV24-40
| 315*237*165mm
| 80A
| 20A
|
EV24-60
| 315*240*215mm
320*237*188mm
460*220*150mm
| 120A
| 30A
|
EV24-80
| 355*330*215mm
| 160A
| 40A
|
EV24-100
| 355*330*215mm
| 200A
| 50A
|
EV24-120
| 400*275*245mm
| 180A
| 60A
|
EV24-200
| 550*210*425mm
| 200A
| 100A
|
EV48-30
| 345*238*200mm
| 60A
| 30A
|
EV48-60
| 590*240*240mm
| 120A
| 30A
|
EV48-80
| 585*345*230mm
| 160A
| 40A
|
EV48-100
| 585*345*230mm
| 200A
| 50A
|
EV48-160
| 605*435*255mm
| 160A
| 80A
|
EV48-200
| 615*650*250mm
| 160A
| 100A
|
EV48-250
| 605*290*480mm
| 200A
| 125A
|
Performance specifications
project
| Features
|
Overvoltage protection
| 3.7V (single string)
|
Undervoltage protection
| 2.8V (single string)
|
Charging parameters
| Maximum 2C lasts for 10 minutes, 1C continues
|
Discharge parameters
| Up to 1C continuous
|
Charge and discharge port form
| Charge and discharge
|
fuse
| Have
|
RS-485 communication
| Have
|
Analog output AO
| Have
|
Configurable DO output
| Have
|
Power LED display
| Have
|
Master switch
| Have
|
Operating temperature
| -20℃~60℃
|
Storage temperature
| -20℃~70℃
|
Working humidity
| Relative humidity of 10% to 80%, no condensation
|
cooling system
| Passive natural cooling
|
Charger requirements
| Lithium iron phosphate battery charger
|
Battery shell color
| Toyota White (customizable)
|
>>
