Made in China, Making Plastic Watering Pot, Spray Blow Molding Machine

Product Description

Foshan Bkwell intelligent equipment co.,ltd
Add: E04-1-04BLOK,LUNJIAO INTENSIVE INDUSTRIAL ZONE,SHUNDE DISTRICT,FOSHAN,CHINA
jwellmachinery.en.made-in-china.com
Description of equipment:
PLASTIC WATER BOTTLE/WATER JUG Blow Molding Machine (We can offer complete solutions:Mould with auto deflashing,Online labeling machine,Take out robot,conveyor,Online leak detector, especially high speed blow molding machine use the lowest tempreture technical).
Product Overview:
Performance&Advantages
·Suitable for producing different size plastic watering pot.
·Adopt continuous type die head, up-blowing structure, convenient for
product auto-deflashing on-line, scrap conveying on line, finished
product leak testing on line, conveying,packing, etc.,reducing the
working cost and increasing the production ratio.
·Adopt toggle type platen structure, have the advatages
of uniform-clamping, big clamp force, assembling large
mould, easier dismounting& assembling the mould.
·Optional hydraulic servo control system.
Technical parameters of machine

Model	Unit	BM2D	BM5D	BM12D	BM20D
Max product volume	L	2	5	12	20
Dry cycle	PC/h	900*2	700*2	600*2	600*2
Die head structure	CONTIUNOUS TYPE
Main screw diameter	Mm	65	75	90	90
Max plasticizing capacity (PE)	Kg/h	70	90	160	160
Driving motor	Kw	22	30	45	45
Oil pump motor power	Kw	7.5	11	15	15
Clamping force	Kn	40	70	120	160
Space between platen	Mm	138-368	150-510	240-640	280-680
Platen size W*H	Mm	286*330	8350*400	450*500	500*520
Max. mold size	Mm	300*350	360*400	500*520	560*520
Platen moving stroke	Mm	420	450/520	600/650	650
Heating power of die head	Kw	6	7.5	10	12.5
Machine dimension L*W*H	M	3.0*1.9*2.4	3.7*3.1*2.7	4.2*3.2*3.0	4.*3.2*3.1
Machine weight	T	5	8.5	12	14
Total power	Kw	45	60	90	93

Blow moulding machine/extrusion blow molding machine samples:
Extrusion Blow molding machine running in our customer workshop
Different kind of Control system of machine

parts name	country	Brand
PLC and touch screen	Germany/Austria	SIEMENS/B&R
Contactor	France	Schneider
Inverter	China/Germany	JWELL/Rexroth
Parison control system	Japan/Austria	MOOG100/B&R 300
Pneumatic valve	CHINA	Air TAC
Hydraulic Control System	CHINA	Famous brand
hydraulic valve	CHINA	Taiwai YUKEN
Take out robot	CHINA	JWELL
Accumulate type Die head	CHINA	JWELL
Driving motor	Germany	SIEMENS-Beide MADE IN CHINA
Gearbox	CHINA	Famous brand
SCREW&BARREL	CHINA	JWELL

seals service network
CERTIFICATE
workshop & oneof the factory(Changzhou city)
Contact us !!
Foshan Bkwell intelligent equipment co.,ltd
Add: E04-1-04BLOK,LUNJIAO INTENSIVE INDUSTRIAL ZONE,SHUNDE DISTRICT,FOSHAN,CHINA
Contact: Jade Liang


Web:jwellmachinery.en.made-in-china.com
jwellmachinery.en.made-in-china.com
FAQ
Q1. Is Jwell Machinery Manufacturer?
A1: Jwell made the first Chinese screw and barrel in 1978 in brand name Jinhailuo. After more than 40 years development, JWELL is one of the biggest extrusion machine supplier in China with 300 design&test engineer, 3000 employees. We own 5 manufacturing bases and sales center in Shanghai , Suzhou , Changzhou, Zhou Shan, Dongguan China. Jwell has become the premier supplier of extrusion lines and reliable business partners. Welcome to drop in us.
Q2: How many brands does Jwell Machinery own?
A2: Jwell Machinery owns more than 20 subsidiaries, China famous brand JINHAILUO, JWELL, BKWELL, DYUN are our Trade Marks.
Q3: If we don't find what we need from your website , What should we do ? Do you make extrusion lines as per customers' specific requirement?
A3: Yes, we can provide bespoke service to customers with specific requirements. You can send the detailed requirements by email. We will check if we can develop them. We develop new machinery every month, and some of them may not yet be updated on our website.
Q4: How do you ensure your machinery and service quality?
A4: Our machines taking the European standards and follow the Germany type of business, we cooperation with International famous brands Siemens Schneider Flender Omron ABB WEG Falk Fuji etc. Our company continuously imports over 1000 international first-class high precision processing equipment such as multistage machining centers, NC lathes and CNC milling machines from Korea, Japan etc. All our processes strictly adhere to CE certification, IS09001 and 2008 quality management system . And we have 12 months quality warranty time. We testing the machine performances before each delivery. Jwell service engineers will always be here for anything you needed.
Q5: How can I order and make payments?
A5: Once clear your requirements and determined extrusion line is ideal for you. We will send technical solutions and Proforma Invoice to you. You can pay via TT bank transfer, LC as you like.
Q6: If we find your bank account or email different as before, how should we respond?
A6: Please don't send the payment and double check with us before arrange payment (Bank details will be listed in every piece of proforma invoice. ) We are only responsible for email
Q7: How long is the delivery date?
A7: Usually it takes about 1 - 4 months depends on different machinery upon receipt of order advance payment.
Q8: What is your Minimum Order Quantity?
A8: One. We provide both customized extrusion lines and technical solutions. Welcome contact with us for technical innovation or improvements for your future purchasing plan.
Q9: What is your production capacity?
A9: We produce more than 2000 advanced extrusion lines every year world wide.
A10: What about shipping?
Q10: We can send the small spare parts by air express for urgent matter. And the complete production line by sea to save the cost. You can either use your own assigned shipping agent or our cooperative forwarder. The nearest port is China Shanghai, Ningbo port, which is convenient for maritime transportation..
Q11: Is there any pre-after sale service?
A11: Yes, we support our business partners by pre-after sale service. Jwell has more than 300 technical testing engineers traveling world wide. Any cases would be responded with prompt solutions. We provide training, testing, operation and maintenance service for a life time.
Q12:Are our business& money safe with Jwell Machinery ?
A12: Yes, your business is safe and your money is safe. If you check China company blacklist, you will see that it is not contain our name as we never crook our customer before. JWELL enjoys high reputation from the customers and our business and customers grows year by year.

---
