Automatic Mineral Water Filling Equipment
Product Description
Water filling machine is used to fill pure water, mineral water and other non-carbonated beverage.
All the machine part which contact with liquid is high quality stainless steel 304. The relative fittings are from international famous brand.
This machine is comprised of rinsing, filling and capping system. Rinsing: grip the bottle neck, rotate filling plate, inverse bottle; internal rinsing and external spraying make bottles be cleaned completely. Filling: gravity filling with holding bottle neck; the special backflow type of the filling valve can avoid leakage after filling and also control liquid level accurately. Capping: magnetic torque bottle holding type can minimize the cap damage rate and make the capping performance the best.
This machine owns the reasonable, stable and safe design. Under the condition that the bottle neck size is the same, only the output star wheel needs to be changed if bottles are different. It improves the efficiency a lot.
We are the water filling machine manufacturers in China.
Machine picture:
Washing Part Filling Part
Capping Part
Main technical data:
| Model | Washing head no. | Filling head no. | Capping head no. | Production capacity(500ml) | Overall size(mm) | Weight(kg) | Power of main motor
(kw)
|
8-8-3
| 8 | 8 | 3 | 1500-2000
| 2050*1450*2100
| 2000
| 1.8 |
14-12-5
| 14 | 12 | 5 | 3000-4000
| 2400*1760*2350
| 2500
| 2.0 |
16-12-6
| 16 | 12 | 6 | 5000-6000
| 2300*1600*2400
| 2800
| 2.2 |
18-18-6
| 18 | 18 | 6 | 7000-8000
| 2650*1900*2400
| 3000
| 3.5 |
24-24-8
| 24 | 24 | 8 | 8000-12000
| 2900*2100*2400
| 3500
| 4.5 |
32-32-10
| 32 | 32 | 10 | 12500-15000
| 3100*2100*2650
| 4300
| 5.5 |
40-40-10
| 40 | 40 | 10 | 15000-18000
| 4350*2880*3200
| 6000
| 5.5 |
50-50-12
| 50 | 50 | 12 | 20000-23000
| 4850*3800*3200
| 7500
| 7.5 |
Company information
Workshop detail
Our team
Our exhibition
FAQ
Q1: How to find suitable machine or complete beverage production line?
A1: Looking for beverage filling machine in www.grandeemachine.en.china.cn
•Enquiry: Contact us by email, phone call, fax, Instant Messenger (Trade manager, Skype, WhatsApp, Wechat) and let us know your requirements
• Discussion: Specify the items and what are you exactly looking for.
Q2: Are you a trading company or a manufactory?
A2: We are the manufacture of water/beverage filling machine and water treatment system over 10 years.We just not only sell drinking water machines and other related equipment , Quality is our culture. We have rich experienced engineers with technicians working team , providing good and after-sales service term , professional salesman terms .
Q3: Do you have technical support after we purchased your machines?
A3: We will arrange our professional technical to go aboard to your factory, they will help you and teach you how to install and maintenance the machines which you purchased. Or help you to fix machine when it has problems.
Q4: If you buy our machines, can you offer us wear-out spare pats?
A4: We provide our high quality machine 2 years guarantee , and we will also offer you 2 years wear-out spare parts for free. Once your machines broken or doesn't work within 2 years and you can't solve it, firstly, we will try to help you to find problems from your words description by phone or other communication tolls. Secondly, if the phone solutions still not work, our engineers will go to your factory to solve it. Meanwhile, they will teach you the related experiences for fixing.
>>
