Product Details
Product Description
Product Description
MAIN FEATURE:
01 Spring clamp, hydraulic station drive release.
02 Anti corrosion design.
03 Equipped with a release limit switch for interlock protection.
04 Power unit with manual pump (applicable to YJE, YJJ series, and only for YJE300, YJJ300 and below specifications).
05 The hydraulic station is equipped with a manual pump and an electrical control box (for YJE and YJJ series, only for YJE400, YJJ400 and above specifications).
06 The YJD series rail clamps are connected by top flange, while all other specifications are connected by end flange.
07 The clamp body has a floating structure: horizontal floating distance ± 20mm, vertical floating distance ± 20mm.
BASIC PARAMETER:
YJA series hydraulic rail clamp:
Product model: YJA160、YJA200、YJA250、YJA315、YJA400、YJA560、YJA600、YJA800、YJA1000、YJA1200
Clamping force (KN): 160, 200, 250, 315, 400, 560, 600, 800, 1000, 1200
Anti slip force (KN): 80, 100, 125, 160, 200, 280, 300, 400, 500, 600
YJD series hydraulic rail clamp:
Product model: YJD160、YJD200、YJD250、YJD315、YJD400、YJD560
Clamping force (KN): 160, 200, 250, 315, 400, 560
Anti slip force (KN): 80, 100, 125, 160, 200, 280
YJE series hydraulic rail clamp:
Product model: YJE50、YJE100、YJE150、YJE200、YJE300、YJE400、YJE500、YJE600、YJE800、YJE1000、YJE1200
Clamping force (KN): 50, 100, 150, 200, 300, 400, 500, 600, 800, 1000, 1200
Anti slip force (KN): 25, 50, 75, 100, 150, 200, 250, 300, 400, 500, 600
YJJ series hydraulic rail clamp:
Product model: YJJ50、YJJ100、YJJ150、YJJ200、YJJ300、YJJ400、YJJ500、YJJ600、YJJ800、YJJ1200
Clamping force (KN): 50, 100, 150, 200, 300, 400, 500, 600, 800, 1200
Anti slip force (KN): 25, 50, 75, 100, 150, 200, 250, 300, 400, 600
>>
