Fully Automatic Guillotine Rubber Cutter/Nature Rubber Cutter Bale Cutting Machine/Hydraulic Guillotine Vertical Rubber Cutter with CE

Product Description

XQL-80 rubber sheet cutting machine, hydraulic cutter
I. Advantages of the cutter
1. Cutting knife: use of high quality alloy 9CrSi, wear-resistant, sharp, high hardness
2. Oil cylinder: use of professional high pressure cylinder seamless steel cylinder; piston rod with 45# steel refined grinding processing after plating, high wear resistance, good toughness; sealing ring with high wear resistance and oil resistance of high quality rubber production, long life, good sealing.
3. The cutter orientation with the copper guide post guide sleeve type structure, accurate orientation, small abrasion, long service life.
II. Technical parameter

Model No.	XQL-80	XQL-125	XQL-160
Rubber cutter stroke (mm)	660	660	660
rubber cutter width (mm)	660	760	1000
Oil cylinder pressure (KN)	80	125	160
Rubber cutting travel time (S)	14-18(45-60mm)	16-18	16-20
Motor power(KW)	5.5	5.5	7.5
Overall dimension	1800*500*2150	1800*500*2150	2200X500X2150

III. Pictures for Reference
IV. Inspection Before Shipment and Loading Pictures for Reference
V. Our machine list
Our company professional manufacture rubber vulcanizing press (frame type,four column type,lab press and so on), rubber mixing mill, batch off cooler, rubber extruder, rubber strip making machine and tire recycling equipment.
VI. Our service
1. Test running: The above machines are all passed inspection of 3~5 hours of full load operation before leaving our factory. And we will take the video and send it to you for inspection. You can use it directly thus saving the time of test-run and expense. And we also warmly welcome to our factory to inspect and test running.
2.Warranty: 12 months after installation, if our machines have any problems, please feel free to contact me. We will solve it for you as soon as possible, and give you the best services.

---
