Longyu 5/8" Electropolished 316L Stainless-Steel Tubing China Suppliers Stainless Steel Pipe 2inch 0.5mm 0.6mm 0.7mm Thick Stainless Steel Tube for Decoration

Product Description

LONGYU 5/8" Electropolished 316L Stainless-Steel Tubing China Suppliers Stainless Steel Pipe 2Inch 0.5Mm 0.6Mm 0.7Mm Thick Stainless Steel Tube For Decoration
Product DescriptionJiangyin Longyu - a pipe and fitting factory that can process various materials.
10-year pipe material customization: ordinary stainless steel, duplex steel, super austenitic stainless steel, ferritic steel, alloy steel, titanium alloy steel, etc.
We are an all-in-one factory that combines welded pipes, seamless pipes, precision pipes, pipe fittings, etc. We have relatively fast delivery speed and control over product quality. "Guaranteed by the quality and developed by science", "Customer needs are the company's pursuit", we pursue "first-class products", "first-class reputation" and "first-class service". Our company is willing to establish honest cooperative relationships with friends from all walks of life for mutual benefit and common development. Welcome customers to Jiangyin Longyu Stainless Steel Welded Pipe Co., Ltd. for a visit and guidance.
What is Electropolished Tubing?
Electropolish Stainless steel is the result of reverse plating, and an electrochemical solution is used to strip away the outer skin of the metal. LONGYU is a prominent manufacturer, stockiest, supplier, and distributor of Stainless Steel Electropolished Pipes & Tubes. Electropolished Stainless Steel Tubing is used for biotechnology, semiconductor, and pharmaceutical applications. The finishing of electroplating has different standards for use in other applications. These applications require a medium range of finish. Electro Polishing is a process that removes the absolute roughness of any metal in an electropolishing plant. This process makes the pipes more accurate in dimensions, and the Ep Pipe can be installed with accuracy in sensitive systems like pharmaceutical industrial applications. Different materials could be electropolished, enabling the Electro-Polished SS Pipes to retain minor contaminants on the surface. These pipes are available in various sizes ranging from 6NB to 1200NB and outer diameters from 1/8" to 12" NPS with thicknesses of 0.6mm to 12.7 mm.
What is Bright Annealed Polished Tube?
Bright Annealed Stainless Steel Tube is a type of tubing made from high-quality stainless steel that has undergone a bright annealing process. The bright annealing process involves heating the stainless steel tube to a high enough temperature to induce recrystallization and remove any residual stress, but below the temperature that would cause any significant oxidation or scaling. Bright Annealed Stainless Steel Tube is a tube with a bright, shiny surface finish and improved ductility and corrosion resistance. This makes bright annealed stainless steel tubes ideal for use in high-precision applications, such as in the pharmaceutical, semiconductor, and biotechnology industries.

Process Classification	Physical polishing (MP)
	Pickling and polishing (AP)
	Bright annealing (BA)
	Electrolyte pickling (EP)

STAINLESS STEEL ELECTROPOLISHED PIPES & TUBES
The seamless pipes are dimensionally accurate and can have less absolute roughness. Electropolishing works when the application is susceptible and needs the inside of the pipe to be as clean and smooth as possible. This procedure is carried out by electrolysis in, where the product loses atom by atom on the surface and comes to a polished finish. However, the process has its downfalls as well. Even with this method, the absolute roughness persists to some extent. These tubes and pipes are used in various applications such as dairy production, brewery, food industry, pharmacy, cosmetics, chemical industry, and more. These pipes and tubes are known for better corrosion, good flow characteristics, improved hygiene, and smooth finish. Electropolished (EP) Tubing
For applications with surface finish requirements well beyond the quality realized in a standard mill finish, we maintain an inventory of electropolished stainless steel tubing in diameters ranging from 1/8" through 1". Through submersion in an electrically charged electrolyte solution bath, a smooth uniform surface is created by dissolving imperfections. This process removes any contamination on or just below the tube's surface and passivates it, bolstering the corrosion resistance of the steel. EP stainless steel tubing is typically used in the following applications:
Sample lines for H2S in chemical processing
Semiconductor fabrication
Sanitary piping systems
Pharmaceutical manufacturingSTAINLESS STEEL PRECISION BA TUBING
Material: 304/ 1.4301/ X5CrNi18-10/ 304H/ S30415/ 1.4948/ S30409/ 304L/ 1.4306/ S30403/ 1.4307/ 316L/ 1.4401/ 1.4404/ 1.4435
The precision bright tube is one of high-precision steel pipe made of fine-drawn or cold-roled. The precision bright tube has the following advantages: no oxidation level on the inside/outside wall, without leakage withstand high pressure, high precision, high degree of finish, no deformation, faring while bending, and flattening without cracks. they are mainly used in the production of pneumatic or hydraulic components, such as cylinders or oil cylinders which can be seamless or welded tubes. chemical components of the precision bright tube have carbon c, silicon si, manganese Mn, sulfur s, phosphorus P, and chromium Cr.A spectrometer will test each lot of raw materials before being put into storage. We wll100% PMl the mother pipe to ensure we put the right material. We will 100 %PMl the finished pipe again to ensure we produce the right grade. This is the way we ensure the chemical quality.
We are using the advanced cold-drawn technology from Japan and Korea, making the close dimension controls. Detailed Photos
Product Parameters

Caliber Code		OD	SCH
Nominal Diameter DN	Inch	Outer Diameter mm	SCH 5S	SCH 10S	SCH 40S	SCH 80S	SCH 10	SCH 20	SCH 30	STD	SCH 40	SCH 60	XS	SCH 80	SCH 100	SCH 120	SCH 140	SCH 160	XXS
6	1/8	Φ10.29	-	1.24	1.73	2.41	-	-	-	1.73	1.73		2.41	2.41	-	-	-	-	-
8	1/4	Φ13.72	-	1.65	2.24	3.02	-	-	-	2.24	2.24	-	3.02	3.02	-	-	-	-	-
10	3/8	Φ17.14	-	1.65	2.31	3.20	-	-	-	2.31	2.31	-	3.20	3.20	-	-	-	-	-
15	1/2	Φ21.34	1.65	2.11	2.77	3.73	-	-	-	2.77	2.77	-	3.73	3.73	-	-	-	4.78	7.47
20	3/4	Φ26.67	1.65	2.11	2.87	3.91	-	-	-	2.87	2.87	-	3.91	3.91	-	-	-	5.56	7.82
25	1	Φ33.4	1.65	2.77	3.38	4.55	-	-	-	3.38	3.38	-	4.55	4.55	-	-	-	6.35	9.09
32	1.1/4	Φ42.16	1.65	2.77	3.56	4.85	-	-	-	3.56	3.56	-	4.85	4.85	-	-	-	6.35	9.70
40	1.1/2	Φ48.26	1.65	2.77	3.68	5.08	-	-	-	3.68	3.68	-	5.08	5.08	-	-	-	7.14	10.15
50	2	Φ60.32	1.65	2.77	3.91	5.54	-	-	-	3.91	3.91	-	5.54	5.54	-	-	-	8.74	11.07
65	2.1/2	Φ73.02	2.11	3.05	5.16	7.01	-	-	-	5.16	5.16	-	7.01	7.01	-	-	-	9.53	14.02
80	3	Φ88.9	2.11	3.05	5.49	7.62	-	-	-	5.49	5.49	-	7.62	7.62	-	-	-	11.13	15.24
90	3.1/2	Φ101.6	2.11	3.05	5.74	8.08	-	-	-	5.74	5.74	-	8.08	8.08	-	-	-	-	-
100	4	Φ114.3	2.11	3.05	6.02	8.56	-	-	-	6.02	6.02	-	8.56	8.56	-	11.13	-	13.49	17.12
125	5	Φ141.3	2.77	3.40	6.55	9.53	-	-	-	6.55	6.55	-	9.53	9.53	-	12.70	-	15.88	19.05
150	6	Φ168.28	2.77	3.40	7.11	10.97	-	-	-	7.11	7.11	-	10.97	10.97	-	14.27	-	18.26	21.95
200	8	Φ219.08	2.77	3.76	8.18	12.70	-	6.35	7.04	8.18	8.18	10.31	12.70	12.70	15.09	18.26	20.62	23.01	22.23
250	10	Φ273.05	3.40	4.19	9.27	12.70	-	6.35	7.80	9.27	9.27	12.70	12.70	15.09	18.26	21.44	25.40	28.58	25.40

Nominal Outer Diameter D(mm)

Nominal Thickness S(mm)

0.51

0.71

0.89

1

1.15

1.24

1.65

2.11

2.41

2.77

3.05

3.18

3.4

3.96

4.78

Φ3.175

×

×

×

Φ6.35

×

×

×

×

×

Φ9.53

×

×

×

×

×

×

×

×

×

×

Φ12.70

×

×

×

×

×

×

×

×

×

×

Φ14.30

×

×

×

×

×

Φ15.88

×

×

×

×

×

Φ19.05

×

×

×

×

×

×

×

×

×

Φ25.40

×

×

×

×

×

×

×

×

×

×

Φ31.75

×

×

×

×

×

×

×

×

×

×

Machinable Materials
EN	TP	UNS		Standard
1.4301	TP304	S30400		EN 10217/7TC1&TC2
1.4306	TP304L			EN 10296-2
1.4307	TP304L	S30403		EN10357
1.4311	TP304LN	S30453		DIN11850
1.4404	TP316	S31600		AD2000W2-W4-W10
1.4404	TP316L	S31603		ASTM/ASME A/SA249
1.4406	TP316LN	S31653		ASTM A269
1.4432	TP316L			ASTM A270
1.4435	TP316L			ASTM A554
1.4436	TP316			ASTM A632
1.4438	TP317L	S31703		ASTM A778
1.4439	TP317LNM	S31726		ASTM/ASME B/SB674
	TP317	S31700		ASTM/ASME A/SA312
1.4449	TP317			ASTM/ASME A/SA688
1.455	TP347	S34700		ASTM/ASME B/SB676
1.4541	TP321	S32100
1.4571	TP316TI	S31653
1.4828	TP309
1.4833	TP309S	S30908
1.4845	TP310S	S31008
1.4878	TP321H	S32109
1.4948	TP304H	S30409
1.4835	253MA	S30815
	ALLOY840	S33400
Ferritic steel
EN	TP	UNS		STANDARD
1.4016	TP430	S43000		ASTM/ASME A/SA268
1.4509	TP441			ASTM/ASME A/SA249
1.4512	TP409			EN10357
1.4521	TP444			ASTM A/SA803
	TP439M	S43932		EN 10296-2
1.451	TP439M			ASTM A554
1.452	TP430Ti
	TP439	S43035
	TP410S	S41008
2.4630		GH3030
Duplex steel
EN	TP	UNS	GRADE	STANDARD
1.4362		S32304	DSS 2304	EN 10217/7 TC1&TC2
1.4162		S32101	DSS 2101	ASTM/ASME/SA789
		S32003	DSS 2003	EN10357
1.441		S32750	DSS 2507	AD 2000 W2
1.4501		S32760		EN 10296-2
		S82031		ASTM A554
1.4462		S31803	DSS 2205	ASTM/ASME A/SA790
1.4462		S32205	DSS 2205
1.4481		S31260
1.4424		S31500
1.4466		S31050
SUPERAUSTENITIC STEEL				STANDARD
EN	TP	UNS	GRADE	EN10217/7 TC1&TC2
1.4529		N08926	1925HMO	EN10296-2
		N08367		ASTM/ASME/SA249
1.4562		N08031	ALLOY 31	ASTM A269
1.4539		N08904	904L	ASTM A270
1.4547		S31254	254SMO	ASTM/ASME A/SA312
				ASTM/ASME B/SB676
				AD 2000 W2
				ASTM A632
				ASTM/ASME B/SB674
				ASTM/ASME A/SA688
				ASTM/ASME B/SB674
				ASTM/ASME A/SA468
NICKEL ALLOYS
EN	TP	UNS	GRADE	STANDARD
2.4602		N06022	ALLOY 22	ASTM/ASME B/SB515
2.4605		N06059	ALLOY 59	ASTM/ASME B/SB516
2.466		N08020	ALLOY 20	ASTM/ASME B/SB626
2.4633		N06025	ALLOY 25	ASTM/ASME B/SB704
1.4563		N08028	ALLOY 28	ASTM B/SB751
1.4876		N08800	ALLOY 800	ASTM/ASME B/SB730
2.4858		N08825	ALLOY 825	ASTM/ASME B/SB468
2.436		N04400	ALLOY 400	AD 2000 W2
2.4816		N06600	ALLOY 600	EN 10217/7 TC1&TC2
2.4851		N06601	ALLOY 601
2.47		N06058	ALLOY 2120
2.4675		N06200	ALLOY C2000
2.4068		N02201	ALLOY 201
2.4733		N06230	ALLOY 230
2.4819		N10276	C-276
2.4856		N06625	ALLOY 625
1.4959		N08811	INCOLOY 800HT
2.4060		N02200	NICKEL 200
2.4600		N10675	Hastelloy B-3
2.4617		N10665	Hastelloy B-2

Company Profile FAQQ1: Are you a trading company or manufacturer?
We are a processing type company specializing in processing stainless steel for 304/304L large diameter thick wall stainless steel welded pipe and other materials. Prompt delivery, low price, high quality, unique insight into various materials of stainless steel, rolled round, straight seam, ring seam.
Q2: What are the company's main products?
304/304L stainless steel welded pipe processing, Thick-walled stainless steel welded pipe processing, Large diameter stainless steel welded pipe processing, Customizable stainless steel shrimp elbow, etc.
Q3:What are the advantages of your company?
We have many professionals, technical personnel, more competitive prices, and better after-sales service than other stainless steel companies.
Q4: What do you do to control product quality?
Before loading into the container, all products will go through a pre-shipment inspection by our professional QC group. UT test is called is applied to steel material, according to Sep 1921 C/c, D/d, or E/e level based on different types of steel.
Q5:What is your MOQ?
Our MOQ for each order is around 25 Tons(one container), customers can mix different types of steel to reach this quantity.
Q6: Can we visit your company and factory?
Yes, warmly welcome! We can book the hotel for you before you come to China and arrange for our driver to our airport to pick you up when you come

---
