| US$19,000.00 | 1 Piece (MOQ) |
| Raytools laser head | |
| Raycus laser source | |
| Yaskawa servo motor and drivers | |
| Motovario Reducer | |
| Taiwan grinding TBI ball screw | |
| Taiwan LAPPING guide rail | |
| 3rd Generation Aviation Aluminum Gantry | |
| Heavy industrial bed | |
| Lenovo computer and Cypcut Software | |
| Full enclosed cover | |
| Saw bed | |
| Industry Chiller | |
| Remote controller | |
| Warranty (except consumable parts) | 3 years for laser and machine |
| Production time | 15-20 working days after prepayment |
| Payment terms | 30%TT before production and 70% before shipping |
Raycus Laser source | High electro-optical conversion efficiency Customized output fiber length QBH connector Maintenance-free operation Wide modulation frequency range Small size, easy to install |
Raytools head autofocus | The BM109 series are auto-focusing laser cutting heads released by RAYTOOLS AG in 2017 for fiber laser processing with 1.5kW or less. This products have a built-in motor drive unit, which drives the focusing lens through a linear mechanism to change position automatically within 17mm.Customers can set the program to achieve continuous focus that completing the rapid piercing and cutting material with different thickness. BM109 use the D28 diameters lense set to collimate and focus the laser beam, which can achieve the diffraction-limited optical effect. The design of water-cooled structure allows laser heads to work stably and chronically. |
Yaskawa servo motor and driver | Real-time auto-gain tuning Manual and auto notch filters Manual and auto damping filters Setup software with motion simulation New structure innovative core high-precision encoder Complies with European safety standards Low interference |
Tongfei Industrial Chiller | Using high-pressure electrostatic spray treatment, the appearance is elegant and unique, and durable. The control system adopts liquid crystal Chinese and English conversion computer controller, fully automatic control, simple and intuitive operation. With automatic fault diagnosis function, the fault point is directly displayed on the screen, prompting the user to process quickly. |
Taiwan guide rail | Hiwin linear slide rails are four-row single arc-arc contact linear slides, and integrate heavy-duty precision linear slides with optimized structural design to improve load and rigidity compared with other linear slides; It has four-direction load characteristics and automatic self-aligning function, which can absorb the assembly error of the mounting surface and obtain high-precision appeal. |
Cypcut visualized interface | Automatic graphics optimization Simple process settings Flexible processing toolbar Rich data statistics Accurate patrol assistance Double deviation self-correction |
France Moto Reducer | The company is located in Saint-Etienne, a traditional production base in Europe. It is created by cooperation between MOTOREDUCER and a well-known French aerospace equipment manufacturing company through years of technical exchanges, global market analysis and strategic planning Highly demanding, higher standards and more comprehensive transmission equipment manufacturing enterprises. MOTOREDUCER planetary reducer has been promoted in the Chinese market since 2010, and has successfully served thousands of industrial equipment manufacturers in various fields. Now, in order to meet the improvement of the overall level of industrial manufacturing and better adhere to the "use technology to create value for the world" concept, in 2018 will launch a higher performance, more comprehensive RECKON-MOTOREDUCER precision planetary gearbox series products. |
Apex Rack and gear | These drives are perfect for a wide range of applications, including axis drives requiring precise positioning & repeatability, traveling gantries & columns, pick & place robots, CNC routers and material handling systems. Heavy load capacities and duty cycles can also be easily handled with these drives. Industries served include Material Handling, Automation, Automotive, Aerospace, Machine Tool and Robotics. The rack product range consists of metric pitches from module 1.0 to 16.0, with linear force capacities of up to 92,000 lb. Rack styles include helical, straight (spur), integrated and round. Rack lengths up to 3.00 meters are available standard, with unlimited travels lengths possible by mounting segments end-to-end. Quality levels available include soft, induction-hardened, quenched & tempered and hardened & ground (up to AGMA 12+ and DIN 4). |
