Z-axis with lifting motor.
| Specification//CODE NO. | Unit | X6332B/63003 |
| Spindle taper | | 7: 24 ISO40 |
| Spindle travel | mm | 150(vertical) |
| Sleeve feed | mm/r | 0.04/0.08/0.15(3 steps) |
| Distance from spindle to column | mm | 200-550(vertical) |
| Distance from spindle to table | mm | 155-455(vertical) |
| Distance fron spindle center to table surface | mm | 0-300(horizontal) |
| Distance from spindle center to arm | mm | 190(horizontal) |
| Spindle speed range | r/min | (20steps) 63-5817(vertical) (12 steps) 60-1350(horizontal) |
| Table size | mm | 1250 × 320 |
| Table travel (x/y/z) | mm | 600 × 300 × 300 |
| Range of longitudinal, cross travel | mm/min | 22-555(8 steps)810(max. ) |
| Vertical up-down speed table | mm/min | 560 |
| T-slot NO. /width/distance of rotary table | mm | 3/14/70 |
| Main motor | mm | 3.7(vertical)2.2(horizontal) |
| Motor for rapid device of table | w | 750 |
| Motor of lifted table | w | 750 |
| Speed of cooling pumps | L/min | 12 |
