Centrifugal Solid Liquid Starch Centrifuge for Wheat Starch Manufacturer

Product Description

Product Description People will crash and separate the mature crops depend on their physical starch separator is the key in the process properties, then obtain starch. So the of starch extraction.In the starch separation process, the separator rotates in high speed then creates the centrifugal force, so the separation efficiency is improved. At the same time maximize the production efficiency. We devote ourselves to make shenzhou starch separator to the most professional and efficient in starch processing industry, it collects all the advantages of various separator such as small vibration, large capacity, stable running and so on. It' s mainly used in pre-concentration starch,separation of starch and gluten,concentration of gluten (protein),clarify of process water in the after step and so on.
Features 1.Big diameter of drum , large area of disk , strong capability of production ( separation ), excellent effect of separation
2.Adopting top - suspension driving which makes the separator with high rotation stability , and largely improves the using life of bearings and main shaft .
3.Adopting automatic control of lubricating oil circuit , which protects and prolongs the using life of driving system .
4.Adopting big nozzles , which has big feed capability , reduces the chances of block , assuring the continuous production .
5.Fitted with hydraulic system for lifting drum , which makes more easily to check the drum and replace nozzles .
6.The material of drum adopts imported high - strength corrosion - proof stainless steel , which assures the safety and stability of separator .7.This machine can be started up when no - load .
8.This machine can treat the materials with various concentration without internal adjustment .
9.Fitted with inner circulation system which keeps the stability of separation and good to adjust and control accurately .
10.Operating easily , the workers can master the operation regulation in short.
Product Parameters

Model	445	630	800	935	1000
Bowl Speed(rpm)	4500-5200	2850-4800	2750-3300	2250-3050	2250-2950
Capacity(T/H)	20~35	30~60	22~115	45~225	45-300
Power(kw)	30	55	110	220	220
Dimension L×W×H(mm)	1284×1407×1457	2000×1000×2050	2800×1500×2200	3200×1800×3100	3200×1800×3100

DPF type separator is mainly consists the feed device, rotating drum, cover, the body,horizontal shaft, vertical shaft, ground water pump, machine base, motor and other components.When the rotating drum running a high speed, when the material enter into the disc separation area through the feeding pump (1), under the action of the centrifugal force field, the starch particles slip to the inside wall of the drum, discharged from the nozzle(2),and the light phase like protein and others will collect to the drum center, discharged out of the machine via centripetal pump(3).The machine has a washing bottom pump, the washing water into the drum from the vertical center hole(4), it is used for washing the yellow paste of the starch material, and effectively improve the quality of starch. Product photos
