Trinocular Manual Routine Stereo Microscope (XTH-3021)

Negotiable 1 Piece (MOQ)

Basic Info.

Model NO.

XTH-3021

Number of Cylinder

Trinocular

Mobility

Desktop

Stereoscopic Effect

Kind of Light Source

Ordinary Light

Shape

Rectangular Prism

Usage

Teaching

Principle

Optics

Principle of Optics

Polarizing Microscope

Name

Stereo Microscope

Model

Xth

Eyepiece

Wf10X/23

Zoom Ratio

1: 6.5

Lens Zoom Range

1X-6.5X

Total Magnification

10X-65X

Field of View

23mm-3.5mm

Working Distance

103mm

Interpupillary Distance

52m-75mm

Binocular or Trinocular Tube

Inclined 45/60

Transport Package

Standard Exporting Packing

Specification

SGS

Trademark

Leader

Origin

China

HS Code

9011100000

Production Capacity

10, 000PCS/Year

Product Description

Trinocular Manual Routine Stereo Microscope (XTH-3021)
Usage:
This stereo microscope is widely used in medical and health, electronics, precision machinery industry and so on, especially suitable to inspect the naked IC, LCD printing paste, PC
Feature:
1) Zoom lens microscope
2) Inclined 45/60 degree observation
3) Erect image
4) Can connect CCD camera
Standard delivery:
Main unit: 1PCS
Eyepiece patch: 2PCS
Anti-dust cover: 1PCS
Optional accessories:
Eyepiece: WF5X, WF15X, WF20X, WF25X, WF30X
Auxiliary lens: 0.5x, 0.75x, 1.5x, 2x
Micro-image process software:
Digital Camera:

Technical data
Zoom ratio	1: 6.5
Lens zoom range	1X-6.5X
Eyepiece	WF10X/23mm
Total magnification	10X-65X
Field of view	¢ 23mm-¢ 3.5mm
Working distance	103mm
Interpupillary distance	52mm-75mm
Binocular tube	Inclined 45º /60º
Diopter adjustment	± 5 diopter
Trinocular body rotation	360º

Eyepiece	WF10X		WF15X		WF20X		WF25X
Auxiliary lens	Magnification	Field of view	Magnification	Field of view	Magnification	Field of view	Magnification	Field of view	Working distance(mm)
0.5X	5X-32.5X	¢ 46-¢ 7.4	7.5X-48.8X	¢ 32-¢ 5	10X-65X	¢ 26-¢ 4	12.5X-81.25X	¢ 24-¢ 3.6	163
0.75X	7.5X- 48.8X	¢ 30.7-¢ 4.7	11.3X-73.1X	¢ 21.3-¢ 3.3	15X-97.5	¢ 7.3-¢ 2.7	18.8X-121.9X	¢ 16-¢ 2.5	117
1X	10X-65X	¢ 23-¢ 3.5	15X-97.5X	¢ 16-¢ 2.5	20X-130X	¢ 13-¢ 2	25X-162.5X	¢ 12-¢ 1.8	100
1.5X	15X-97.5X	¢ 15.3-¢ 2.4	22.5X-146X	¢ 10.7-¢ 1.6	30X-195X	¢ 8.7-¢ 1.3	37.5X-243.8X	¢ 8-¢ 1.2	45
2X	20X-130X	¢ 11.5-¢ 1.8	30X-195X	¢ 8-¢ 1.2	40X-260X	¢ 6.5-¢ 1	50X-325X	¢ 6-¢ 0.9	40
