US$30.00-70.00
|
1 Piece
(MOQ)
|
Basic Info.
Output Signal Type
Analog Type
Feature
Corrosion Resistant
Production Process
Normal Wirewound
Installation Mode
Easy to Install
Sealing Mode
Laser Sealing
Other Characteristics
Preventing of Oil, Moisture and Corrosion
Capacity
0.25t, 0.5t, 1t, 2t, 3t, 5t
Rated Output(Mv/V)
2.0000±0.002
Specification
43cm*40cm*23cm
Production Capacity
30000PCS/Year
Product Description
Actual application scenario
Product Parameters
Feature Adopting high-precision resistance strain principle With unique technology, stable for property Laser sealing, insurance for using surrounding Stainless steel material optional, preventing of oil, moisture and corrosion Specification
| Capacity | 0.25,0.5,1,2,3,5t | Material | stainless steel |
| Rated Output(mV/V) | 2.0±0.002 | Non-linearity | ±0.02%FS |
| Hysteresis | ±0.02%FS | Repeatability | ±0.01%FS |
| Creep(30 minutes) | ±0.02%FS | Zero balance | ±1.00%FS |
| Temperature effect on zero | ±0.02%F.S./10ºC | Temperature effect on output | ±0.02%F.S./10ºC |
| Input resistance(Ω) | 381±4 | Output resistance(Ω) | 350±3 |
| Insulation resistance | ≥5000MΩ | Excitation voltage | 5V-15V(DC) |
| Compensated temperature range | -10~+40ºC | Operating temperature range | -40~+65ºC |
| Safe overload | 150%FS | Breaking loading | 300%FS |
| Cable | Φ5 X 5M
Or customized by request | Cable color code | Input: green+ black-
Output: white+ red-
|
Outline Drawing Plan Dimension
| Rated load (t) | A | B | C | D | E | F | G | H | K | M | N | P |
| 0.25,0.5,1 | 133.4 | 76.2 | 25.4 | 16.4 | 30.7 | 30 | 57.9 | 17 | 4.8 | 12.7 | 22 | 15.9 |
| 2 | 136.7 | 76.2 | 25.4 | 16.7 | 36.8 | 36.6 | 57.9 | 23 | 9.5 | 12.7 | 22 | 15.9 |
| 3 | 139.7 | 79.2 | 25.4 | 16.7 | 39 | 36.6 | 57.9 | 23 | 9.5 | 15 | 22 | 15.9 |
| 5 | 171.5 | 95.2 | 38.1 | 16.7 | 42.9 | 43 | 73.8 | 29.4 | 11 | 19 | 34.9 | 22.2 |
Application Mainly suitable for ground weighing, chemical, building materials and other industries ingredients weighing control.
Detailed Photos
