Screen Basket for Waste Paper Pulp Making Machine Spare Parts

Product Description

Screen Basket for Waste Paper Pulp Making Machine Spare Parts
Application:
It is suitable for different screening process of a variety of slurry to achieve fine screening.
Design Features:
Wide adaptability and large production capacity.
High pulp flow speed and high production efficiency.
JS series outflow screen is especially suitable for fine screening of waste paper pulp. The screen/sieve basket adopts a high-strength wedge wire type, with large slurry throughput and long service life. The rotor adopts a multi-wing rotor or a cylindrical rotor, and the pulse frequency is high, which is beneficial to the cleaning of the screen gap. Extend the action time of the negative pressure pulse to ensure the continuous operation of the screening process. The specially designed pressure screen rotor can effectively avoid the enrichment phenomenon during the screening process.
The removal rate of impurities such as stickies is high.
Simple structure and easy maintenance. Low energy consumption and cost savings.
Technical Parameters:

Model	JS0.4	JS0.8	JS1.2	JS1.5	JS2.0	JS3.0	JS4.0
Screen hole size(mm)	1.2-3.0
Screen slot size(mm)	0.15-0.75
Capacity(24hours)	50-100	60-200	80-300	90-360	120-450	180-600	220-900
Inlet consistency(%)	High consistency 2-5%, low consistency 0.6-2%
Inlet pressure(Mpa)	0.15-0.3
Motor power(kw)	15-55	30-75	30-90	45-110	75-132	110-260	132-280

Remark: The yield will change due to different types of pulp, consistency and other factors. The capacity in the table is only for selection.
Accessories Equipment:
Wedge Wire Screen Basket of Paper Pulp Machine
Description:
The corresponding bars can be configured according to different raw materials and screening positions to ensure customer needs.
Processing Range:
Deviation of slot width should be controlled within 0.02mm.
Chroming thickness is 0.20-0.30mm.
Surface hardness is more than HRC 60-66(HV700-900)
Plate area:0.4-23m2
Flange: SUS304
Wedge bar material: SUS316L
Slot size: normally 0.25mm
The most proper wedge wire will be selected based on different raw materials and screening position to develop good performance and achieve optimized screening cut by meeting customers' demands. Our material of wedge wire is using SS316L and no fiber string after mechanical polishing, while good machining ensures good matching of wedge wire and support ring, which ensure evenness for screening cut.
About Us
GLM was founded in 2010, and is an integrated company dedicated to the pulp and paper industry associated with planning, design, research, development, producing, delivery, testing and training. Besides, GLM was funded by the Pulp and Paper Design Institute, Pulp Equipment Mill and Paper-making Machinery Company, and in turn gathers together talents from each part. Furthermore, an impressive result has been achieved in recent years.
GLM is devoted to the technological development of the pulp and paper industry and works together with senior experts for updating or rebuilding it as well. In addition, it can provide one-stop service regarding project plan and design, staff training, technical support and more with our new customers.
The headquarters of the GLM Company is located in Weifang CBD. It provides a very good service with customers through more than 20 people's design and research teams, more than 10 people's project management expert teams, more than 40 people's technical service teams and two spots of more than one hundred people's production base. In a word, the continuous pursuit goal of GLM is to provide the optimal solution with each customer.

---
