| Turning-parameters | |
| Max. swing over bed | 420mm |
| Max. swing over cross slide | 150mm |
| Distance between centers | 500mm |
| Large carriage travel | 440mm |
| Middle carriage travel | 200mm |
| Spindle taper | MT4 |
| Spindle bore | 28mm |
| Max. travel of tail-stock sleeve | 70mm |
| Taper of tail-stock | MT3 |
| Threads metric pitches | 0.7~6mm |
| Threads inch pitches | 4~120TPI |
| Longitudinal feed / Lateral feed | 12 kinds |
| Spindle speed range | 160-1360RPM(7 steps) |
| Motor power | 0.75KW |
| Drilling and milling-parameters | |
| Max.Drilling capacity | 25mm |
| Max.milling capacity | 80mm |
| Max.vertical milling capacity | 16mm |
| Table size | 475mm×160mm |
| Spindle taper | MT3 |
| Spindle travel | 110mm |
| Distance from spindle to column guide rail | 285mm |
| Distance from spindle end to table surface | 306mm |
| Spindle speeds | 120~3000RPM (16steps) |
| Motor power | 0.75KW |
| Net weight/gross weight | 245/275KG |
| Overall dimensions | ≈1460x580x965mm |
| Package Size | ≈1430x580x1100mm |
