Panic Buying High Rigidity Saudi Arabia Home Mini Oil Press Machine

Product Description

https://winglobal-machinery.en.made-in-china.com/product/kGzrujIvXMhP/China-Spiral-Oil-Expeller-Rapeseed-Peanut-Oil-Press-Machine.html
Product Description
The 6YL-105 spiral oil press is a specially designed oil press equipment for the oil processing industry, suitable for cold pressing various types of oil. It has the characteristics of large processing capacity, easy operation, high oil yield, low cake residue, clear oil color, and rich nutrition.

Structural diagram of spiral oil press
Application:
The 6YL-105 spiral oil press can extract various types of oil, including peanuts, soybeans, rapeseed, cottonseed, sesame, olives, sunflowers,coconuts, oil palm fruits, etc. These oilseeds are widely used in the production of edible oils to meet the needs of different consumers.
Advantage:
1.Simple and easy operation,one key to start without other operating2.The residual oil content does not exceed 7 percent3.Reliable transmission systems are mostly helical gears with greater torque4. Pure copper motors are more powerful and less failure rate5. Reasonable design and configuration of strip and round row ensure faster oil output and higher oil yield6. Stainless steel oil guide plate is cleaner and more sanitary7. Advanced automatic stirring forced feeding system ensures the uniformity and continuity of feeding8. Convenient and labor-saving adjustment and disassembly system facilitates product adjustment and maintenance Detailed Photos
Product Parameters
Standard Technical Parameters of 6YL Series Screw Oil Press Series:

MODEL	CAPACITY(T/D)	POWER(KW)	DIMENSIONS (MM)	OIL RESIDUE (%)	SHAFT SPEED (rpm)	WEIGHT (KG)
6YL-68	1--1.5	5.5	1000*550*950	≤7	120--130	140
6YL-80	2--3	7.5	1400*580*1100	≤7	40--50	300
6LY-95	3--5	11	1700*600*1350	≤7	30--40	460
6YL-100	4--6	11	1700*600*1300	≤7	30--40	460
6YL-105	5--7	11	1850*650*1400	≤7	45--55	560
6YL-120	6--8	15	1850*650*1400	≤7	45--55	560

The Use Of Machines
Preparation before startup
1.After installing the expeller, fill the lubricating oil according to the regulations, check whether the parts are fastened, and whether the operation
handle and insert plate are flexible.
2.Move the big triangle belt wheel by hand to make the machine rotate, check whether the moving parts are normal, whether there is any foreign
matter stuck in the press chamber, if not normal, it should be excluded.
3.Check and adjust the tightness of the belt.
4.loosen the anti-loosening nut, according to the direction of the arrow pointed to trigger the handle, so that the slag slightly head and cake ring
contact, and then return 3-4 turns, and then forward half a circle, to ensure that the slag slightly head and the gap between the cake ring.
5.Start the motor, the direction of rotation of the big triangle belt wheel should be consistent with the direction of the mark (arrow). Carry out the
empty running test of the oil press, generally running for about half an hour. During the operation, you should pay attention to the sound and
temperature of the oil press, if you find any abnormal phenomenon, you should stop the machine to check and eliminate.
Factors affecting oil output rate
Following factors may affect oil output rate:
1.Water content:This is the critical factor,as a matter of fact,water content directly affects oil output rateHowever, user usually has not proper
inspection equipment.Hence,water content of some main raw material maybe detected as follows:
(1) Bean: if teeth beating could crack it,forming flat pieces accompanied with light sound the watercontent is suitable.Flat piece without cracking
means too wet.Heating or sunshine may be drive'wateroff.However,cracking accompanied with loud indicates too dry. Adequate water needs to
be added.
(2) Cotton seeds: shell and kernel may be separated by teeth beating. Shell breaking may be accompaniedby sound, which means water content is
suitable .shell being flatting indicates too wet, shell being splitted intopowder means too dry.

(3)Rape seeds: They can be pressed either at hot or at cold state. Cold pressing: extruding by finger, ifthey splitted into two pieces, accompanied by
sound and oil,this implicates water content is adequate.Otherwise,extruding makes power indicates too dry; makes flat slice, too wet. Hot pressing
(after heating) :Toscratch seeds by two slices of wood, if shell and kernel could be splitted, water content is adequate. If kernelbecomes power, it is
too dry; in the case that shell and can be splitted, it is too wet.
2.Cakes thickness reflects the pressure inside the chamber. Thicker cake indicates lower pressure insidethe chamber; thinner cake-higher pressure
inside. If raw material has less oil content, chamber pressure shouldbe higher, cake will be thinner, round plates need to be tightened; in the case of
high oil content material,pressure in the chamber should be lower, then circular plates need to be loosened, resulting in thicker cake.Recommended
thickness of cakes will be.
Bean:1.1-1.Smm for the first time;0.5-1mm for the second time.
Cotton seeds : only one pressing,1-2mm.
Ground nut kernel : Normally cold pressing for 2-3 times,1-2mm
Important note: cakes thickness should be as according to different factors to achieve highest oil outputrate.Hence, above figures will only be for
reference.
Company Profile
Henan Winglobal Machinery a fully integreated factory enterprise of design, manufacturing and sales of oil presses. It is designated by the former
Ministry of Industrial Machinery as the recognised oil press manufacturing base, with 40 years history till now.We are proud of our sophisticated equipment and rich technical expertise. Guided by the principle of "Dependable Quality, Reasonable Price, Timely Delivery, Considerate Aftersales", we have established firm and ever growing relationships with customers both at home and abroad.We passed ISO in 2000, and in 2008 we achieved CE certificate. With our strength, our oil press products come with less energy consumption, and best oil yield rate. The oil press can be used to squeeze oil from all types of granular or powder oil seeds, including soybean, peanut, sunflower seeds, tung seeds, mustard seeds, castor seeds, palm fruit, palm kernel/fibre, coconut, rapeseeds, moringa etc.Apart from the above, we also manufacture the combined automatic oil press, auxiliaries of all sorts, palm oil processing complete line, oil refinery set and so on.
Why Choose us

Decent price
Quick delivery
Durable quality
We are honored to cooperate with your respectable business anytime!

---
