Warping Beaming Machine Rebeaming Machine Sizing Machine

US$65,000.00-150,000.00 1 Piece (MOQ)

Basic Info.

Model NO.

GA283

Condition

New

After-sales Service

Available

Application

Yarn Rebeaming

Match Machine

Warper, Sizer

Machines

Complete Production Line

Beam Width

1780-2400mm

Transport Package

Wood Box

Specification

Customizable

Trademark

28

Origin

Jiangsu Province

HS Code

8445902000

Production Capacity

300 Sets/Y

Product Description

Product Description
Main features
• Flexible beam stands (one layer, double layers, semi-double layers)
• Magnetic powder brake or motor drive precisely controls draw-off tension
• Equipped with tension rollers for tension measurement (when motor drive is used)
• Individual tension control for each beam stand
• Wide range tension control (from extra low to extra high)
• Hydraulic lift for beaming lifting & doffing
• Stable take-up tension in acceleration, deceleration and uniform speed
Product Parameters
Technical data

Beam stand working width	1780mm/2000mm/2200mm/2400mm
Beam stand beam diameter	800mm/1000mm
Type	One layer (semi-double or double layers)
Brake system/drive system	Magnetic powder brake (negative) or motor drive (positive)
Take-up working width	2400mm/2800mm/3000mm/3200mm/3600mm
Take-up beam diameter	800mm/1000mm/1250mm
Max. speed	150m/min
Standard equipment	Static eliminators, safety bar, infrared detectors
