Topic: Solar generator system 24v solar hybrid inverter 7000 6000 1000watt pure sine wave power
| Mode | BR-IN-1000 | BR-IN-1500 | BR-IN-2000 | BR-IN-3000 | BR-IN-4000 | BR-IN-5000 | BR-IN-6000 | BR-IN-7000 |
| rated power | 1000W | 1500W | 2000W | 3000W | 4000W | 5000W | 6000W | 7000W |
| peak power | 3000W | 4500W | 6000W | 9000W | 12000W | 15000W | 18000W | 21000W |
| Input | Voltage | wide input voltage range(130V-280V AV) or narrow input voltage range(160V-260V) is optional |
| Frequency | 45-65Hz |
| Ouput | Voltage | AC220V±3%(battery mode) |
| Frequency | 50/60Hz±1%(battery mode) |
| Output waveform | Sine wave |
| Efficiency of the whole machine | >85% |
| Battery type | Lead-acid,lithium-iron,gel,ternary and customized |
| Nominal voltage of external battery | 12/24/48VDC | 12/24/48VDC | 24/48VDC |
| Max charging current of mains supply | 80A(12VDC),40A(24VDC), 20A(48VDC) |
| Protection | Overloaded,short-circuit, over-temperature, over/low voltage of battery, over/low voltage of mains supply protection |
| Conversion mode | Interactive 5MS(typical) |
| Overload capacity | Maintain 60 seconds when 110%-120%, maintain 10 seconds when 150% |
| Communication interface | RS-232(optional) |
| Operating environment | Temperature | 0-40ºC |
| Humidity | 10%-90% |
| L*W*H(mm) | 370*210*170mm | 485*230*210mm | 540*285*210mm |
