China Manufacturer′s Direct Sales Dual Axis Solar Tracking Mounting System Solar Tracker

Product Description

/Dual Axis Solar Tracking System/
· Higher efficiency, +25%-40% more energy
· No back shadows design for bi-facial solar modules
· Simple structure: Easy for installation and maintenance
· Less power consumption: Only about 3-5kWh/set/year
· High frame strength: Better wind-resistance performance
· Single pole supporting structure: Best terrain adaptability
· Reliable technology, low failure rate, high tracking accuracy
· Smart control, self-positioning & self-correction, low O&M cost
· Rain wash mode: Effectively reduce your solar panels washing times
· Snow prevention mode: Effectively increase your power generation time
· No fixed coverage to sunshine or raining: No affection to plants growing
/Technical Date/

Item	Parameter
Control Mode	Time + GPS
Average Tracking Accuracy	0.1°-2.0°(adjustable)
Gear Motor	24V/1.5A
Output Torque	5000 N.M
Tracking Power Consumption(Per Set)	<0.01kwh/day
Azimuth Angle Tracking Range	+-50°
Elevation Angle Tracking Range	50°
Max. Wind Resistance in Horizontal	>40 m/s
Max. Wind Resistance in Operation	>24 m/s
Material	Hot-dipped galvanized>65μm
System Guarantee	3 years
Working Temperature	-40°C - +75°C
Technical Standard & Certificate	CE, TUV
Weight(Per Set)	150-250 KGS
Total Power(Per Set)	1.5kW-5.0kW

/Main Parts of Dual Axis Solar Tracking System/

Item	Description	Weight(kg)	Total Weight	Dimension(mm)	Quantity
1	Vertical Pole	45.8	45.8	2000*200*200*2.5	1
2	L-shaped Bracket	15.7	15.7	770*194*5	2
3	Center Beam	43.1	43.1	120*120*4700*2.2	1
4	Swing Arm	5.6	5.6	380*100*50*3.5	1
5	Swing Arm Fixing Plate	2.2	2.2	212*110*120	1
6	Plastic Bearing	0.2	0.8	Φ 120	4
7	Plastic Bearing Limit	0.25	0.5	36*50 Angle Steel	2
8	Plastic Shaft Sleeve	0.1	0.2	Φ 60*45	2
9	Steel Shaft Sleeve	0.4	0.8	70*5	2
10	Elevation Linear Actuator	7.0	7.0		1
11	Azimuth Linear Actuator	7.5	7.5		1
12	Azimuth Linear Actuator Fixing Plate	0.9	1.8		2
13	Supporting Beam	8.1	40.5	55*32*7.5*4578	5
14	Inclined Strut	2.2	11.0	34*16*1.8*2200	5
15	Control Unit Seat	0.7	0.7		1
16	Control Unit	1.0	1.0		1

---
