Product Details
Product Description
Product Description
Product Description:
High quality PA500 PA1000 PA1500 PA2000 tension clamp anchor clamp for ADSS fiber optic cable
Low voltage Overhead Line Fitting plastic Anchoring clamp with stainless steel rope for optical fiber cables type ADSS, Automatic conical tightening. Opening bail easy to be installed.
All the parts secured together.
Standard: NFC33-042.
Material
Clamp body made of weather and UV resistance Polymer or aluminum alloy body with polymer wedge core.
Adjustable link made of hot dip galvanized steel(FA) or stainless steel(SS).
Features
A pair of wedges grips the cable automatically within the conical body.
The installation does not require any specific tools and the operating time is drastically reduced.
| Item | Type | Applicable cable diameter | Breaking Load | Application |
| Tension clamp | PA2000 | 8-14mm | 8KN | for ADSS fiber optic cable |
| Universal pole bracket | UPB | / | 10KN |
| Suspension clamp | J-HOOK | 5-8mm
8-12mm
10-15mm
| 4KN/10KN |
| Stainless steel band & buckles | SS201 | size:19*0.7mm
|
|
|
Our Service :
1. we are one if the earlist ,large-scale professional manufacture for high quality electric power fittings since 1990 ,located in Yongnian the famous "capital of Electric "in China .
2. With factory area more than 25,000m2, we can produce 90 series of(1000 types of products) Electric Power Fitting products including overhead insulation fitting, electric cable fitting, substation fitting, line fitting, electric station fitting, installation tools, link fitting, suspension clamp, protection fitting, connection fitting and so on. We also accept OEM/OBM business per customer requirement. Our product has been exported to Russia, Middle East and South Asia with highly comment.
3. We always insist strict quality control management system approved by ISO9001:2008, and also was awarded with the honors of “Credible Enterprise "
Contact Me:
Email :cindy6662021@163.com
whatsapp:+86-18233030851
>>
