| Duty | 0.1 ~ 99.9% ±(1.5%+2) | |
| Ignition Frequency | 0.1Hz ~ 100KHz ±(2.0%+2) | |
| Pulse Width | 0.1 ~ 999.9ms ±(3.0%+5) | |
| DC V | 2/20/200/1000 V ±(0.5%+3) | |
| AC V | 2/20/200/700 V ±(1.0%+3) | |
| DC A | 20m/200m/20 A ±(1.0%+2) | |
| AC A | 20m/200m/20 A ±(1.5%+2) | |
| Resistance | 200/20K/200K/20M Ω ±(1.0%+3) | |
| Temperature | -40°C~1000°C ±(1%+3) | |
| Party cycle | 1%~90% | |
| TACH | 500-10000RPM 3/4/5/6/8CYL ±(1.5%+5) | |
| DWELL | 0°~120° 3/4/5/6/8CYL ±(1.5%+5) | |
| Diode test | yes | |
| Transistor test | yes | |
| Continuity buzzer | yes | |
| Data Hold | yes | |
| Auto Power OFF | yes | |
| LCD MAX. Count | 1999 | |
| terminal sockets with automatic blocking system | yes | |
| Power | 6F22(9V) |
| Product Size | 200*85*38 mm |
| Product Net Weight | 700g |
| Standard individual packing | gift box |
| Standard Quantity per Carton | 20 pcs. |
| Measurement of Standard Carton | 480*370*335mm (0.059 CBM) |
| Gross weight of Standard Carton | 18kgs |
