US$5,000.00-10,000.00
|
1 Piece
(MOQ)
|
Basic Info.
Model NO.
XL6032 XL6032C XL6032CL
Type
Knee Type Milling Machine
Milling Cutter Type
Vertical Milling Cutter
Milling Cutter Structure
Indexable Type
Controlling Mode
Artificial
Certification
CE, RoHS, ISO 9001
Vertical Travel(mm)
460mm
Transport Package
Plywood Case
Production Capacity
10 PCS/Month
Product Description
Milling Machine
Horizontal Swivel Table Miling Machine XL6032
1.Rotary table can be ordered at special request
2.Driven by AC Servo Motor
3.Table automatic feed on X,Y,Z
4.Automatic rapid feed X,Y,Z
Specification of swivel table milling machine
SPECIFICATIONS:
| SPECIFICATION | UNIT | XL6032 | XL6032C | XL6032CL |
| Spindle taper | - | 7:24 ISO50 |
| Distance between spindle nose and table | mm | 20-480 | 20-470 |
| Distance from spindle axis to arm | mm | 175 |
| Spindle speed range | - | 12steps 60~1800r.p.m |
| Table size | mm | 1325X320 | 1600X320 |
| Table travel(X/Y/Z) | mm | 750/320/460 | 1100/320/450 | 1300/320/450 |
| Table feed(X/Y/Z) | mm/min | 30-750 / 20-500 / 15-375 |
| Table rapid speed (X/Y/Z) | mm/min | 1200/800/600 |
| T-slots(NO:/width/pitch) | mm | 3/18/70 |
| Arm travel | mm | 500 |
| Main motor power | kw | 5.5 |
| Torque of X/Y/Z axis AC servo motor | N.m | 10 |
| Overall size | mm | 1800X2100X1870 | 2245X2100X1870 | 2520X2100X1870 |
| Net weight | kg | 2400 | 2465 | 2510 |
L6136 rotating worktable milling machine
| Specification | Unit | XL6036 | XL6036C | XL6036CL |
| Spindle taper | - | 7:24 ISO50 |
| Distance between spindle nose and table | mm | 20-480 | 20-470 |
| Distance from spindle axis to arm | mm | 175 |
| Spindle speed range | - | 12steps 60~1800r.p.m |
| Table size | mm | 1325X360 | 1600X360 |
| Table travel(X/Y/Z) | mm | 750/320/460 | 1100/320/450 | 1300/320/450 |
| Table feed(X/Y/Z) | mm/min | 30-750 / 20-500 / 15-375 |
| Table rapid speed (X/Y/Z) | mm/min | 1200/800/600 |
| T-slots(NO:/width/pitch) | mm | 3/18/70 |
| Arm travel | mm | 500 |
| Main motor power | kw | 5.5 |
| Torque of X/Y/Z axis AC servo motor | N.m | 10 |
| Overall size | mm | 1800X2100X1870 | 2245X2100X1870 | 2520X2100X1870 |
| Net weight | kg | 2450 | 2515 | 2560 |
>>
