PVDF or Powder Color Coated or Anodized Aluminium Panel for Curtain Wall Cladding & Decoration

Product Description

Keywords: metal wall panel, metal wall cladding panel, Wall cladding, metal wall panel, aluminum wall panel, exterior wall panel, interior wall panel, perforated aluminum sheet, curtain wall panel, metal wall cladding, aluminum wall cladding panel, aluminum curtain wall panel, aluminum sheet, aluminum panel, aluminum ceiling panel, aluminum composite panel, aluminum honeycomb sandwiched composite panel, customized aluminum panel, perforated aluminum panel, corrugated aluminum panel, expanded aluminum panel, expanded metal mesh, aluminum plate, aluminum roll, aluminum composite sheet, aluminum alloy, building decoration material.
Aluminum is one of the most popular materials for curtain wall or called facade cladding and decoration on the modern building construction and decoration market. With features of good formability, design flexibiity, light weight, high strength and resistance, affordable prices and variety of surface finish and colors, aluminum panels are widely applied for facade envelope, roof covering and ceiling decoration.
Aluminum curtain wall cladding panels are made from aluminum alloy sheets by laser or CNC machine cutting, bending and shaping, welding, grinding and polishing, assembling, chromating and spray coating. The popular thickness of aluminum panels is 1.5mm, 2.0mm, 2.5mm, 3.0mm, 4.0mm and 5.0mm etc. and common applied alloy is A1100, A3003, A5052 and A5083. The surface finish can be done by polyester powder coating, PVDF oil coating and anodizing.
All the aluminum panels are customized and fabricated according to project specifications and requirements, architecture designs and framing systems.
We're ISO9001:2008 certified manufacturer, professional OEM and ODM factory. All the aluminum panels are produced according to customer's specifications, designs and drawings. The Aluminum panels are fabricated according to ASTM, BS, AAMA and GB regulations or customer's local standards and requirements.
Descriptions
Aluminum panels are made from high quality Aluminum alloy and coated with PVDF (Polyvinylidene Fluoride) resin and color paints. The popular alloy code is 1100 and 3003 for architacture cladding and decoration, we're certified and authorized by PPG for applying Duranar coatings. Hyperbolic shapes are available to match architecture designs.
The PVDF coated Aluminum panel is very popular for exterior wall cladding and decoration, the coating is durable and good weather resistant, it is very suitable for tough condition. You can choose all colors and multi-colors on panel is available.
The wooden color Aluminum panel is very popular for building decoration, you can use it interior and exterior decoration to make natural decoration effects. We have many options of colors to meet customer's demands.
The stone (marble, granite) color Aluminum panel is very popular for building decoration, you can use it interior and exterior decoration to make natural decoration effects. We have many options of colors to meet customer's demands.
The Perforated Aluminum panel is very popular for building decoration, you can use it behid or in front of glass curtain wall to make special decorations. We have many options of patterns to meet customer's demands, the customers can also design the patterns by themselves to make their own styles.
With good mechanical properties of Aluminum alloy, the Aluminum panels can be fabricated in different sizes and shapes according to the building designs and installation drawings to match architecture designs and styles.
the Aluminum panels can serve the buildings very well for cladding and decoration, the light weight and easy installation of the Aluminum panels also help a lot for the construction of buildings, you can save a lot time and labour for installation and finish of buildings.
The surface finish PVDF coatings have very good weather and chemical resistance as well as discoloration proofing, the color of surface can stay for over 15 years in any severe weather condition, and the surface is easy for cleaning and maintaining.
The composition of Aluminum panels is prefabricated Aluminum sheets, stiffeners on back for support of surface and fixing backets. You can also put thermal or sound insulation materials in the back of Aluminum panels to make good insulation of buildings.
Specifications

Material	Aluminum alloy
Alloy code	A1100, A3003, A5052 or other specified alloy
Thickness	1.5mm, 2.0mm, 2.5mm, 3.0mm, 3.5mm, 4.0mm etc.
Size	Customized according to framing dimensions
Design	Customized according to framing and architecture designs
Manufacturing crafts	Unrolling, cutting, punching, bending, welding, grinding, polishing, assembling, chromating and spray coating or anodizing.
Anti-rust treatment	Chromate treatment and spray coating or anodizing
Decoration Surface Finish	PVDF coating, Polyester coating, powder coating, imitated wood or marble grains transfer printing
Color	Any single color or imitated wood or marble colors
Coating thickness	35-120 Microns
Warranty	15 years
Applications	Curtain wall cladding, interior wall covering, eave envelope, awning covering, canopy covering, column envelope, ceiling, roofing etc.
Delivery time	20-35 days subject to order quantity

Features
Terms and Conditions

Quote terms	FOB, CFR, CIF	Payment terms	T/T or Irrevocable documentary L/C at sight
Down payment	Negotiable	Minimum order quantity	Negotiable
Production period	20-30 days	Warranty	15 years for PVDF coating, 5 years for Polyester and powder coatings.

Professional manufacturer provides quality products and considerate services. We are the best supplier and partner for you!

---
