| BRAND | LEKING | ||||
| MODEL | KV 25 | ||||
| Bucket Capacity | 0.035m3 | ||||
| Chassis Width | 1100mm-1400mm | ||||
| Track Length | 1500mm | ||||
| Gradeability | 40° | ||||
| Chassis Ground Clearance | 385mm | ||||
| Track Width | 230mm | ||||
| Volume of fuel tank | 16L | ||||
| Overall Dimension | 3550*1400*2203mm | ||||
| Transport Length | 3550mm | ||||
| Excavator Height | 2203mm | ||||
| Engine Power | 18.2kw | ||||
| Max.Dumping Height | 3016mm | ||||
| Max.Digging Depth | 2133mm | ||||
| Max.Dumping Height | 2050mm | ||||
| Max.Digging Radius | 3800mm | ||||
| Turning Radius | 1645mm | ||||
| Bucket excavating force | 16KN | ||||
| Operating Weight | 1800kg | ||||
