3mm Super Flux LED - Lead Free

Product Description

3mm Super Flux LED
ELECSOUND
Features
High Flux Output
Low Profile
Low Thermal Resistance
Low Power Consumption
Pb free
Descriptions
This revolutionary package design allows the light designer to reduce the number of LEDs required and provide a more uniform and unique illuminated appearance than with other LED solutions. This is possible through the efficient optical package design and high-current capabilities
The low profile package can be easily coupled with reflectors or lenses to efficiently distribute light and provide the desired light appearance
Usage Notes:
The ultra bright LED is an electrostatic insensitive device, so static electricity and surge will damage the LED. It is required to wear a wrist-band when handling the LED. All device, equipment, machinery, desk and ground must be properly grounded
When using LED, it must use a protective resistor in series with DC current about 20mA
Applications
Automotive Exterior Lighting
Electronic Signs and Signals
Special Lighting application.

Device Selection Guide
LED Part No.	Chip	Lens Color
	Material	Emitted Color
9555W2C-HSC-E	InGaN	White	Water clear
Absolute Maximum Rating (Ta=25C)

Part Number	Chip			Lens Type	VF(V) If=20mA	IV(mcd) If=20mA	Angle 2θ1/2
	Material	Emitted Color	Wave Length λD(nm)

9555R1C-HSA-C	AlGaInP	Red	620-635	Water Clear	1.9-2.3	1000-1500	80
9555Y1C-HSA-C	AlGaInP	Yellow	580-595	Water Clear	1.9-2.3	1000-1500	80
9555G3C-HSA-A	InGaN	Green	520-530	Water Clear	2.9-3.5	1100-1600	80
9555B2C-HSA-B	InGaN	Blue	460-470	Water Clear	2.9-3.5	800-1300	80
9555W2C-HSC-C	InGaN	White		Water Clear	2.9-3.5	3300-4000	80

9355R1C-HSA-C	AlGaInP	Red	620-635	Water Clear	1.9-2.5	1000-1500	75
9355Y1C-HSA-C	AlGaInP	Yellow	580-595	Water Clear	1.9-2.5	1000-1500	75
9355G3C-HSA-A	InGaN	Green	520-530	Water Clear	2.9-3.5	1100-1600	75
9355B2C-HSA-B	InGaN	Blue	460-470	Water Clear	2.9-3.5	800-1300	75
9355W2C-HSC-C	InGaN	White		Water Clear	2.9-3.5	3300-400	75

Product Overviews
We currently offer a broad range of capacitors, LEDs, Cermet Trimming Potentiometers, PCBs, Semiconductors, Transistors, Zinc Oxide Varistors, Switches and Resistors.
Company Information
Elecsound is an ISO Certificated manufacturer of high quality, high reliability electronic components, formed in January of 1996. Our staff has over 10 years of experience with excellent English. All of our employees have a strong work ethic and a strong commitment to provide the high quality products that consistently meet or exceed our customer's requirements.
Certificates
Packaging & Shipping
FAQ
1: How long is your lead time?
It depends. Normally, it is 2-6 working days if the goods are in stock, or it is 7-40 days if the goods not in stock.

2: What is your terms of payment ?
For small amount orders, 100% better paid by PayPal or T/T in advance. For large amount orders like more than
10000USD, 30% T/T in advance , balance fully paid before shipment.

3. Do you have any MOQ limit for an order?
Yes, we have MOQ. different items have different MOQ. We will mark MOQ when we quote.

4: How to proceed an order?
Firstly, let us know your requirements or application. Secondly, we quote according to your requirements or our suggestions. Thirdly, customer confirms the samples and pay deposit for the official order. Finally, we arrange the production and ship once it's ready.

5: Do you accept online orders?
Sure!! We prefer to fulfil orders under Trade Assurance system, since both parties will be protected.

6: Do you provide samples? is it free or extra?
Yes, normally we could offer samples with free charge but do not pay the shipping freight.

7: How do you guarantee my goods right?
Order will be arranged exactly as requested, we will doubly check the packing and qty before delivering out also we will take you photos if required or necessary.

8: Is it OK to print my logo on the packing?
Of course, customized packing accepted!! But it may bring some cost, it depends on the qty, if small qty then we don't accept.
