Used Zoomlion 20m Diesel Straight Boom Aerial Worker Garbage Truck Sanitation Truck Special Aerial Worker

Product Description

Pay Attention please!
Our company mainly sells used sanitation trucks! Different prices for different years! Please contact us for details!
Reliable Zoomlion ZA20RJE Electric Platform Lift for Professionals
HIGHLIGHTS
Center layout, great structural rigidity, and small boom deflection
Advanced dual control system (valve control + pump control) offers a energy-saving, smooth and efficient control
±90° Jib rotation offers great up and over height
Compact dimension of 1.19m (3ft 11in) stowed width, ideal for narrow working conditions
Tubular batteries feature long working time and lifespan, and easy for maintenance
FEATURES
Standard Features
Proportional control Load sensing system All motion alarm 4.3' LED display
Flashing beacon Horn
Self-closing entry gate Timer
Emergency descent system Jib rotation
Emergency stop button Vertical lifting function Auto-leveling system Thumb joystick for steering On-board diagnostic system 35A battery smart charger
Over tilt protection system Battery level display
Solid seamless tire Low electric quantity protection
Accessories & Options
Platform light
AC power to platform
Airline to platform
Electric auxiliary pump
Platform console cover (Rated capacity reduced by 10kg)
Anti-crushing device (Rated capacity reduced by 10kg)

Product Parameters

Type	ZT20IE-V/ZT20JE-VLi	ZT23JE-V/ZT23JE-VLi
Dimension
Maximum working height	20.60m	22.95m
Maximum platform height	18.60m	20.95m
Maximum working range	13.3m	15.5m
A storage length (arm folded)	9.74m(7.6m)	9.4m(6.8m)
B storage width	2.28m	2.46m
C Storage height	2.57m	2.7m
D Working platform length	1.83m	2.44m
EWorking platform width	0.76m	0.91m
F Wheelbase	2.52m	2.52m
Wheelbase	2.28m	2.46m
G Minimum Ground Clearance	0.33m	0.33m
Capabilities
Rated load	300kg	300/454kg
Traveling speed (stow status)	5.2km/h	5.2km/h
Maximum Climbing Capacity	45%(24°)	45%(24°)
Inner Turning Radius	2.69m	2.69m
Outside turning radius	5.45m	5.45m
Turning angle of turntable	360°sequential	360°sequential
Platform swing angle	±90°	±90°
Tail swing	1.7m	1.7m
Flying arm swing angle	135°(-60°~75°)	130°(-55°~75°)
Maximum working wind speed	12.5m/s	12.5m/s
POWER
Battery	2*24V/440Ah(lead acid) 51.2V/315Ah(lithium)	2*24V/440Ah(lead acid) 51.2V/375Ah(lithium)
Chargers	48V/60A	48V/60A
Drive motors	3.3KW	3.3KW
Lift Motor	10KW	10KW
Auxiliary power	12V DC	12VDC
Hydraulic tank	75L	75L
Tire
Tire Model	33×12D610	33×12D610
Weight
Over weight	8600kg	10400kg

SIZE


FAQ
1. Q: How about the quality of your trucks?
A: Wuhan Ring Valley Environment mainly sells medium and high-end sanitation trucks, no matter the chassis, engine and so on are all belong to the top equipment. Our trucks get ISO 9001: 2008 and CCC, B&V and other related certificates.
2. Q: Is there any advantages of your price?
A: We don't only have new truck but a large selection of used trucks. Different products in different years are available at different prices. We'll be sure to help you find the best vehicle in suitable price.
3. Price term: FOB, CIF.
4. Payment: 30% deposit after order confirmation, 70% balance should be paid before delivery. All are by T/T, L/C.
5. Delivery time: 7-20 working days after payment is received.
6. Standard Steering: Left-hand drive, if you need Right-hand drives, please inform us, we will make special order for you.
If you have any other questions, please feel free to contact us at any time.

---
