| US$3,000.00-50,000.00 | 1 Piece (MOQ) |
| MODELS | C0632A | C0636A | |
| CAPACITY | |||
| Max. swing over bed | 330mm | 360mm | |
| Max. swing over gap | 476mm | 508mm | |
| Max. swing over slide | 198mm | 228mm | |
| Width of bed | 186mm | ||
| Max. length of workpiece (two centers) | 500/750/1000mm | ||
| SPINDLE | |||
| Spindle nose | D4 | ||
| Spindle bore | ะค38mm | ||
| Taper bore of spindle | M.T.NO.5 | ||
| Steps of spindle speed | 8 | ||
| Range of spindle speed | 70~2000rpm | ||
| FEED | |||
| Range of longitudinal feeds | 0.0026-0.040 in/r (0.067~1.019 mm/r | ||
| Range of cross feeds | 0.0009-0.0138 in/r (0.018~0.275 mm/r) | ||
| THREADING | |||
| Inch threads | 3-1 /2~80T.P.I/ 36 kinds | ||
| Metric threads | 0.45-10mm/ 27 kinds | ||
| TAILSTOCK | |||
| Travel of tailstock quill | 95mm | ||
| Taper bore of tailstock quill | M.T.NO.3 | ||
| OTHERS | |||
| Main motor | 2HP(1.5KW) | ||
| Net weight/Gross weight(1000mm) | 495/595kg | 510/610kg | |
