Zoomlion 6cbm Mixing Capacity Self Loading Concrete Truck Mixer

Product Description

Product Description 1. Original imported engine
An Imported engine that provides powerful performance and low fuel consumption. The overall system is optimised to provide a comprehensive performance upgrade.
2. Latest fuel filter
The latest fuel filer improves filtration and ensures oil inlet quality, thus improving the reliability of the machine under harsh operating conditions.
3. Hydraulic system
Original imported high-end hydraulic components are configured to match capabilities for excellent performance.
4. Structure
Finite element analysis is used in the structural design to strengthen key components so that they can withstand greater stress. This ensures that the machine stays durable under different harsh operating conditions.
5. Optional match
Optional tools include a breaker, a cold temperature activation device, and falling object protection, all to increase the
capabilities of the machine. Detailed Photos
Product Parameters

Structure Parameter	Upper Structure Mass	kg	4150
	Dimensions(L×W×H)	mm	5905×2500×2725
	P.T.O Type		Engine P.T.O
	Water Supply Type		Air Pressure Type
	Volume of Water Tank	L	600
	Air Tank Joint		M22×1.5
Drum Perfor ce Parameter	Agitator Capacity	m3	6
	Gradient of the Drum	o	14
	Max Speed of the Drum	rpm	12~16
	Charge Speed	m3/min	≥4
	Discharge Speed	m3/min	≥3
	Remnant Ratio of Discharging	%	≤0.7
	Range of Slump mm		50~210
Hydraulic System	Pump		REXOTH Dextrorotatory A4VTG090 or others
	Motor		REXOTH AA2FM80 or others
	Gear Box		P4300 or others
	Hydraulic Circuit		Closed
