P2 P2.6 P2.9 P3 P3.91 P4 P4.81 P5 P6 mm High HD Stage Advertising Outdoor Billboard Full Color Rental Panel Indoor Wall Video LED Display

Product Description

We are a professional manufacturer of LED display. We have excellent R&D department,independent design ability.
Our main products include led single color display, indoor full color led display screen, led display, outdoor full-color led to wireless car use screen, etc. Can be used for shopping, banking, bus station, railway stations, urban centers, airports, schools, factories, buses, taxis,creative/flexible screen and so on.
Advertising LED displays, Stadium perimeter LED screen, Mobile led display for mobile media, shopping mall LED billboard for logo showing, bank & stock exchange LED message signs for rates showing, train & bus station, airport, telecommunication LED video wall, stage performances, conference room, etc.
For this indoor fixed LED display, it has been quite popular on the market. It gets the advantages as below,
1. Die-cast Aluminum cabinet, light and thin cabinet, fast heat dissipation, for 1000*250mm cabinet, 5.8kg/pc, thickness 33mmonly 2. Direct connection from module to Hub card, cableless, simple and stable 3. Magnetic module, full front maintenance, save the installation space 4. Can used for curved design LED display 5. Optional pitch and cabinet size available
6. Wide viewing angle 7. High refresh rate and gray color, for 16:9 ratio 8. Different installation options, structure free, can make hanging installation or fix against/in the wall directly to save the project cost

Technical specifications

Environmental
Part Number	XD1000-1.7	XD1000-1.9	XD1000-2.6	XD1000-2.9	XD1000-3.9	XD1000-4.8
Pixel Pitch (mm)	1.736	1.953	2.604	2.976	3.91	4.81
LED Configuration	SMD1010	SMD1010	SMD2020	SMD2020	SMD2020	SMD2020
Pixel Density (dot/m2)	331776	262144	147456	112896	65536	43264
Module Size (mm)	250 * 250	250 * 250	250 * 250	250 * 250	250 * 250	250 * 250
Module Resolution (dot)	144*144	128*128	96x96	84x84	64x64	52x52
Cabinet Size (mm)	1000*250*33 750*250*33 500*250*33	1000*250*33 750*250*33 500*250*33	1000*250*33 750*250*33 500*250*33	1000*250*33 750*250*33 500*250*33	1000*250*33 750*250*33 500*250*33	1000*250*33 750*250*33 500*250*33
Cabinet Resolution (1000*250)	576 * 144	512*128	384 * 96	336 * 84	256 * 64	208 * 52
Cabinet Weight (±0.5KG)	6	6	6	6	6	6
IP Rating ( front/back)	IP32	IP32	IP32	IP32	IP32	IP32
Brightness Intensity (CD/m2 )	600	600	800	800	800	800
Viewing Angle (H/V)	140°	140°	140°	140°	140°	140°
View Distance	>2m	>2m	>3m	>3m	>4m	>5m
Gray Scale (bit)	14	14	14	14	14	14
Max.Power Consumption (W)	160	160	160	160	160	160
Ave.Power Consumption	53	53	53	53	53	53
Refresh Frequency (HZ)	3840	3840	1920 / 3840	1920 / 3840	1920 / 3840	1920 / 3840
\Brightness Adjustment	0 - 100 levels adjustable
Control Mode	Synchronous display with control PC by DVI
Operation Power	AC100/240 50/60HZ
Operating Temperature	- 20ºC~+50ºC
Operating Humidity	10~90% RH
Operating Life	100,000hours
Certificate	CE(EMC, LVD), ROSH, FCC

Started in 2013, Shenzhen XD Vision is a professional manufacturer of LED display, with excellent R&D department, independent design ability. XD VISION is fully capable to provide creative and custom-made LED models beside of standard LED screens.
XD Vision contains of experienced team leaders and each of them has been working in LED display industry over 10 years. All of our R&D, Production, Sales, Technical Support depts are running efficiently and smoothly. Moreover, delivering qualified product and offering timely pre-after service are also assured by XD VISION team.
XD Vision products include led single color display, indoor and outdoor full color led display screen, advertising poster led display, outdoor full-color led for wireless car use screen, etc. These LED display can be used for shopping mall, banking, bus station, railway stations, urban centers, airports, schools, factories, buses, taxis, monitor center, museums, theaters, cinema, sports field, so on. The types of LED display including Advertising LED displays, Stadium perimeter LED screen, Mobile led display for mobile media, shopping mall LED billboard for logo showing, bank & stock exchange LED message signs for rates showing, train & bus station, airport, telecommunication LED video wall, stage performances, conference room, etc.
XD VISION main markets are among America, Europe, Middle East and Asia, all of our products are certificated by ROHS, CCC, CE, FCC, CNAS, etc. With high quality, in the past years of development, XD VISION continuous growth, XD has established the Australia Branch and LED displays have been sold to over 120+ countries all over the world.
AUSTRALIA BRANCH
Address: F3, 13-15 Kevlar Close, Braeside VIC 3195, Australia
Q&A
Q1. Could I get a sample order of led display?
A: Yes, sample order is available to check the quality.
Q2: Could we print our own logo on led display products?
A: Of course. You can send us your logo design and info to confirm before production.
Q3: Do you offer guarantee for the led display products?
A: Yes, we offer one year warranty for our products.
Q4: Do you provide technical training (installation training and user training)?
A: Yes, we offer full service, Including pre-sale, sale, after-sales service for your clientsQ5: Do you accpet other trade terms, like CIF, CFA, etc.?
A: Yes, please send us your destination address and way of shippment, we can check for you the cost for insurance and freight.
Q6: Do you custom design for different shapes?
A: Yes, we can design and manufacturer custom design LED display according to requirements.Factory and workshop
Aging workshop and Project cases
Constrcution of Creative LED display
For Broadcast Station
For night Club
Round/circluar cylindrial creative LED display,
Flexible and Creative LED display
Round/Sphere/Hexgonal(Honey Comb) LED display
Flexible module for Convex and concave with dancing floor
certificates
Package and delivery

---
