Taiwan Factory Direct Sales High Speed CNC Milling Machine Centre

US$27,000.00
1 Piece
US$25,000.00
2+ Pieces

Basic Info.

Model NO.
VMC850
Application
Metal
Process Usage
Metal-Cutting CNC Machine Tools
Movement Method
Contour Control
Control Method
Closed-Loop Control
Numerical Control
CNC/MNC
Processing Precision
0.01~0.02(mm)
Performance Classification
Economical CNC Machine Tools
Certification
CE
Condition
New
Spindle Taper
Bt40
Spindle Motor
7.5/11kw
System
Syntec/Mitsubishi/Fanuc/Siemens
Max Load
650kg
Name
Mold Cutting CNC Vertical Machining Center
X/Y/Z Speed
36/36/36 M/Min
Tool Alignment
Auto Tool Checking
Working Table
1000*500
Precision
+-0.008mm
Repeat Precision
+-0.005mm
Power
5.5kw 380V 3 Phase
Spindle Speed
12000 Rpm
Max Working Speed
6m/ Min
Applicable Industries
Machinery Repair Shops, Manufacturing Plant, Mold
Type
4 Axis CNC Machine
Transport Package
Sea Worthy Plywood Case
Specification
2700*2900*2850
Trademark
WT
Origin
Dongguan City China Prc
HS Code
8457101000
Production Capacity
2000PCS/Year

Product Description

VMC-850 Precision 5 Axis CNC Machine Center Vertical Milling Machine Tools Machining Center
Product Description
The fixed-column vertical machining center machine tool adopts mechatronics design, beautiful appearance, and can be used for precision cutting. After the workpiece is clamped once, the machine tool can automatically and continuously complete the processing of various processes such as milling, drilling, boring, expanding, reaming, tapping, etc. Used in auto parts, valves, construction machinery, T equipment, optical equipment, medical equipment and aerospace industries
Product Paramenters
Item unit VMC-650 VMC-850 VMC-1166 VMC-1270 VMC-1580
Journey
Three-axis travel (X/Y/Z) mm 600/500/550 800/500/500 1100/630/600 1200/700/700 1500/800/800
Distance from spindle centerline to column guide surface mm 480 556 690 768 800
Distance from spindle nose to work table mm 120-570 120-620 150-750 110-870 120-920
Workbench
Table size (length X width) mm 700X420 1000X500 1300X680 1300X700 1600X800
Maximum load kg 600 800 1000 1200 1400
Number of T-slots X Slot Width X Spacing 3X18X100 5X18X100 5X18X110 5X18X150 7/18/130
Spindle
Spindle speed rpm 12000 12000 12000 12000 1000
Spindle taper hole BT40 BT40 BT40 BT40 BT40
Spindle motor power kw 5.5/7.5 7.5/11 11/15 11/15 11/15
Speed
Rapid traverse speed (X/Y/Z axis) m/min 48/48/48 36/36/36 30/30/30 30/30/30 30/36/48
Cutting feed rate m/min 10/10/10 10/10/10 10/10/10 10/10/10 10/10/10
Tool magazine
Number of tools T 24 24 24 24 24
Tool diameter/length/weight Ф75mm/300mm/7kg Ф75mm/300mm/7kg Ф75mm/300mm/7kg Ф75mm/300mm/7kg Ф75mm/300mm/7kg
The maximum diameter of the tool (full knife / adjacent empty knife) mm 75/150 75/150 75/150 75/150 75/150
Machine tool accuracy
Positioning accuracy (X/Y/Z) mm 0.008 0.008 0.01 0.01 0.012
Repeated positioning accuracy (X/Y/Z) mm 0.005 0.005 0.006 0.006 0.008
Other
Air source/air pressure 280L/min6-8bar 280L/min6-8bar 280L/min6-8bar 280L/min6-8bar 280L/min6-8bar
Total capacity of machine tools KVA 20 20 25 35 20
Tank volume L 400 400 420 260 250
Machine tool dimensions (X/Y/Z) mm 2400X2450X2500 2600X2500X2500 3100/2550/2550 3400X2850X2800 4500X3500X3100
Machine Weight (Approx.) kg 4500 5800 9000 9800 11000
