| Model No. | 160STD |
| Generator Set | Rated Frequency | HZ | 50 | 60 |
| Prime Power | KVA | 15 | 17 |
| KW | 15 | 17 |
| Standby Power | KVA | 16 | 19 |
| KW | 16 | 19 |
| Rated Voltage | V | 115/230 | 120/240 |
| Rated Current | A | 130/65.2 | 141.7/70.8 |
| Rated Speed | r/min | 1500 | 1800 |
| Control Panel |
| Smartgen 4010 Display |
| Output | Socket |
| No |
| Terminal |
| Yes |
| Noise（ at 7m） | dB(A) | 62 |
| Machine Size | mm | 1200×660×750 |
| Machine Weight | kg | 470 |
| Alternator | Alternator Model |
| YP160STD |
| Number of Poles |
| 4 |
| Phase |
| Single |
| Excitation Method |
| Brushing self excitation constant voltage (With AVR) |
| Power Factor | COSΦ | 1 |
| Insulation level |
| H |
| Diesel Engine | Model |
| 488M |
| Engine Type |
| Four cylinder inline, four stroke, direct injection, water-cooled |
| Bore×Stroke | mm | 98×105 |
| Displacement | L | 3.17 |
| Compression Ratio |
| 18.2∶1 |
| Rated Power | KW | 20 | 22 |
| Cooling water volume(engine only) | L | 6 |
| Lubrication method |
| Pressure Splash Composite |
| Oil No. |
| CD grade or above，SAE 10W-30、15W-40 |
| Oil Tank Volume | L | 8.5 |
| Start Method |
| 12V Electric |
| Volume of Start Alternator | V-KW | 12V 1.4KW |
| Fuel Consumption | g/KW.h | 215 |
| Fuel No. |
| Diesel： 0＃（Summer）-10＃（Winter）-35＃（Severe cold） |
