| Item | Parameters | Description |
| Power Supply | Input voltage | 9~36VDC |
| Input current | Normal: 130mA@12V. Maximum: 800mA@12V | |
| Connection | 3.5mm wiring terminal | |
| Protection | Anti-reverse connection Protection | |
| WAN | Qty | 1 |
| Interface Spec | RJ45 interface, 10M/100Mbps, adaptive MDI/MDIX | |
| Protection | ESD ±30kV (contact), ±30kV (air) EFT 40A (5/50ns) Lightning 24A (8/20µs) | |
| LAN (non-POE) | Qty | 1 |
| Interface Spec | RJ45 interface, 10M/100Mbps, adaptive MDI/MDIX | |
| Protection | ESD ±30kV (contact), ±30kV (air) EFT 40A (5/50ns) Lightning 24A (8/20µs) | |
| Serial Port | Qty | 1 |
| Type | 1 Channel RS485 or RS232 | |
| Baud rate | 1200,2400,4800,9600,14400,19200,38400,57600,115200,230400 | |
| Data Bit | 5,6,7,8 | |
| Parity | None, Even, Odd | |
| Stop Bit | 1,2 | |
| Working mode | Transparent transmission, Modbus RTU to TCP, Modbus slave, Modbus master ( R10A support but R10 can't) | |
| Protection | ESD contact: 8KV Surge: 4KV (8/20us) ESD ±8kV (contact), ±15kV (air) EFT 4KV, 40A (5/50ns) | |
| WIFI | Antenna Port qty | 2 |
| Antenna type | SMA hole type | |
| Protocol | 802.11a/b/g/n (mixed) | |
| Mode | AP mode, client mode | |
| Frequency | 2.4G | |
| Channel | Channel 1 - 13 | |
| Security | Open, WPA, WPA2 | |
| Encryption | AES, TKIP, TKIPAES | |
| Connection number | 16(Max) | |
| Speed | 300Mbps(Max) | |
| Transmit Distance | Max. 20 meters in open space where there is no obstruction | |
| SSID Broadcast Switch | Support | |
| Cellular Network | Antenna Port Qty | 1 |
| Antenna Port Type | SMA hole type | |
| SIM | Qty | 1 |
| Interface Spec | Drawer interface, support 1.8V/3V SIM/UIM card (NANO) | |
| Protection | Built-in 15KV ESD protection | |
| GPS (optional) | Antenna qty | 1 |
| Antenna type | SMA hole type | |
| Tracking Sensitivity | > -148 dBm | |
| Horizontal Accuracy | 2.5m | |
| Protocol | NMEA-0183 V2.3 | |
| Indicator light | SYS | System running indicator (blinking for 2S and then off after normal operation) |
| 4G | 4G cellular operating status indicator ( when SIM registered successfully, this indicator always on ) | |
| WAN | WAN status indicator | |
| LAN | LAN status indicator | |
| System | CPU | MIPS CPU, main frequency 580Mhz |
| Storage | 128Mbits SPI Flash | |
| RAM | 1024Mbits DDR2 | |
| Software | Network Protocol | PPP, PPPoE, TCP, UDP, DHCP, ICMP, NAT, HTTP, HTTPs, DNS, ARP, NTP, SMTP, SSH2, DDNS |
| VPN | IPsec, OpenVPN, L2TP | |
| Firewall | DMZ, DoS defense, IP packet, domain name and MAC address filtering, port mapping, access control | |
| Remote Management | Supports web remote configuration | |
| System Log | Support | |
| Firmware Update | Supports serial port local TFTP and Web upgrade | |
| Certificate | EMI | EN 55022: 2006/A1: 2007 |
| EMS | IEC(EN)61000-4-2(ESD) IEC(EN)61000-4-3(RS) IEC(EN)61000-4-4(EFT) IEC(EN)61000-4-5(Surge) IEC(EN)61000-4-6(CS) IEC(EN)61000-4-8 | |
| Others | CE, FCC, ROHS, 3C | |
| Working Environment | Working temperature | -20~+65ºC |
| Storage temperature | -40~+85ºC | |
| Humidity | 5 ~ 95%RH (non-condensation) | |
| Others | Enclosure | Metal material |
| Size | Height 110mm * Length 83mm * Width 30mm | |
| IP level | IP30 | |
| Net weight | 300g | |
| Installation | Wall mounted, DIN rail |
